Table 50 Warning event codes (continued)
Details and SolutionDescriptionEvent code
compatibility information see “Backward read
compatibility” (page 60).
Check the SCSI cable connection and verify that
the maximum cable length is not exceeded. Verify
that the SCSI bus is properly terminated.
SCSI message error70
SCSI parity error71
SCSI invalid message72
The application software made an illegal request.SCSI: overlapped command attempt73
SCSI: echo buffer overwritten74
Update the library to the most current firmware
version.
Download prevented — barcode reader
hardware requires newer code revision.
75
This can happen if a cartridge is moved without
the library completing a full inventory. Rescan the
tapes from the RMI or OCP.
Destination element unexpectedly full.76
Update the library to the most current firmware
version.
Download prevented because of an incompatible
library controller.
77
Update the library to the most current firmware
version.
Download prevented because of incompatible
robot firmware.
78
The library will only accept signed firmware
images. Download a signed firmware image.
Invalid firmware version. Only signed firmware
images are allowed.
7B
Recovered error move operation. No action
required. Occasional retries are normal operation.
Movement retry. Robotics movement did not
succeed but was successful on a retry.
80
• Check the tape drive fan on the library back
panel to see whether the fan is operational and
not obstructed.
NOTE: The sub-error code indicates the affected
tape drive. For example, 00 is drive 1 and 01 is
drive 2.
NOTE: Fan only operates when cooling is
required.
Drive sled fan alert. Fan motion has stopped.81
Clean the indicated tape drive using a valid
cleaning tape.
Clean request from the tape drive82
NOTE: The sub-error code indicates the affected
tape drive. For example, 00 is drive 1 and 01 is
drive 2.
Evaluate media status using L&TT.Media attention83
Evaluate drive status using L&TT.Tape drive tape alert; tape drive reported a
warning or critical tape alert.
84
DHCP request has failed85
• Check the network to ensure connection to the
DHCP server.
• Check that the network configuration is correct.
• If DHCP is enabled, ensure that the DHCP
server is up and running on the device's
network.
• Power cycle the device and retry the operation.
Insert a valid cleaning cartridge into the library.Autoclean media warning; not enough media
present to support autocleaning.
86
192 Troubleshooting
