HP Insight Management 7.3 Support Matrix

Table 11 Matrix KVM Private Cloud solution limits and scalability
ValueSolution limits and scalability
If the Matrix configuration is federated, it must be attached to the primary CMSMatrix KVM Private Cloud per
Matrix CMS
Up to 100Tenants
Up to 2500 managed VM guestsVMs
Up to 1000Images
Up to 100Flavors
Up to 4096IP addresses
Insight Control server provisioning hardware
Insight Control server provisioning is a VM appliance that runs on a separate VMware vSphere
(ESXi) or Microsoft Hyper-V host. It requires two IP addresses; a management address that is used
to connect to the appliance web interface and REST API, and a deployment IP that is used for
communicating with the target servers. The appliance can be configured in either single NIC
configuration where the two IPs share the same NIC, or a dual NIC configuration where each IP
is on a separate NIC.
In a single NIC configuration, both IP addresses must be in the same subnet and must have
connectivity to the target servers, the target server iLOs, and the media server. In a dual NIC
configuration, NIC1 is considered the management NIC and is used to connect to the appliance.
NIC2 is considered the deployment NIC and must have connectivity to the deployment NIC on
each target server and the media server. Connectivity to the target server iLOs can be through
either the deployment or management NIC.
Insight Control server provisioning and Insight Control server deployment cannot be active on the
same network at the same time because they both make use of PXE. They should be configured
on separate networks or only one can be actively configured for booting at a time. Table 12
(page 13) lists the hardware requirements for Insight Control server provisioning based on the size
of the configuration (demo, small or large). At a minimum, the Insight Control server provisioning
appliance must have at least 4 CPUs, 16 GB memory, and 200 GB of disk space.
Table 12 Insight Control server provisioning VM resource requirements for vSphere (ESXi) or Hyper-V
LargeSmallPOC/DemoHardware component
Any ProLiant G6, G7, or Gen8 server with an iLO processorServer
844Processor
30 GB16 GB16 GBMemory
200 GB (Thick)200 GB (Thick)200 GB (Thin provisioned)Boot disk
1
Same as bootSame as bootSame as bootData disk
A new appliance is configured with two network interfaces but can be configured to use
one or both of them. Appliances upgraded from a previous version will have a single
interface, but can have a second one added if desired.
Network adapter
Hardware and firmware 13
