Specification Sheet

SP106 Rev F
9-15
Miller Scorpion™ PFL
Description
The lightweight, compact design of the 9 ft. (2.7 m)
Miller Scorpion Personal Fall Limiter provides workers an
affordable alternative to shock-absorbing lanyards. In a
head-to-head comparison with shock-absorbing lanyards,
the Scorpion web retractable requires less fall clearance,
offers greater mobility and prevents tripping hazards.
Materials
Housing: Thermoplastic Cover/Aluminum
Extrusion
Thread: Polyester
Connectors: Drop Forged Steel or Aluminum
Webbing: Polyester/Vectran
Technical
Max. Weight Capacity: 310 lbs. (140.6 kg)
Working Length Capacity: 9 ft. (2.7 m)
Max. Arrest Distance: 24 in. (.6 m)
Avg. Arresting Force: 900 lbs. (4 kN)
(When tested to ANSI Z359.14)
Max. Peak Arresting Force: 1,800 lbs. (8 kN)
(When tested to ANSI Z359.14)
Max. Peak Arresting Force: 900 lbs. (4 kN)
(When tested to OSHA 1926.502
and CSA Z259.2.2)
Ultimate Strength: 3,000 lbs. (13 kN)
Certication
Meets OSHA 1926.502, OSHA 1910.66, ANSI A10.32-2012,
*ANSI Z359.14-2012 Class A and B, and CSA Z259.2.2
Type 1 requirements.
Connecting components meet or exceed ANSI Z359.12-
2009 or CSA Z259.12-11 requirements for 3,600 lb. gate
strength. For questions about products purchased prior to
January 1, 2015, please contact Honeywell Technical
Service at 800.873.5242.
