Key features
www.hikvision.com
DS-2CD6362F-I(S)(V)
6MP Fisheye Network Camera
• 1/1.8” progressive scan CMOS
• 6 mega-pixel image sensor
• Up to 3072 x 2048 real-time streaming
• 360° view angle
• Multiple viewing modes
• Multiple ePTZ streams with preset and patrol functions
• Ceiling, Wall or Table mount modes
• Up to 10m IR range
• Audio/Alarm IO optional/RS485 (-S)
• Outdoor version optional (-V)
DS-2CD6362F-I(S)(V)
Camera
Image Sensor 1/1.8” progressive scan CMOS
Min.
Illumination
0.05 lux @ (F1.2, AGC ON)
0.3 lux @ (F2.8, AGC ON )
0 lux with IR
Shutter Speed 1/25 (1/30)s ~ 1/100,000s
Lens 1.27mm @F2.8, angle of view: 360°
Lens mount M12
Day & Night ICR
Compression Standard
Video Compression H.264/MJPEG
H.264 Type Baseline Prole / Main Prole / High Prole
Video Bit Rate 32 Kbps – 16 Mbps
Audio Compression G.711/G.726/MP2L2
Audio Bit Rate 64Kbps (G.711) / 16Kbps (G.726) / 64Kbps (MP2l2)
Max. Resolution 3072 x 2048
Frame Rate
High-frame Mode: support
50Hz: 1 x sheye (3072 x 2048, 25fps) or (2048 x 2048, 25fps) or
4 x PTZ at (1024 x 768, 30fps)
60Hz: 1 x sheye (3072 x 2048, 25fps) or (2048 x 2048, 30fps) or
4 x PTZ at (1024 x 768, 30fps)
Multi-channel Mode: support
50Hz: 1 x sheye (1280 x 1280, 12.5fps) and 1 x panoramic (2048 x 1536, 12.5fps) and 3 x PTZ
(1024 x 768, 12.5fps)
60Hz: 1 x sheye (1280 x 1280, 15fps) and 1 x panoramic (2048 x 1536, 15fps) and 3 x PTZ
(1024 x 768, 15fps)
Number of Streams
High Frame Rate Mode: 1 or 4
Multi-Channel: up to 5
(No sub-streams)
Digital Noise
Reduction
3D DNR
Wide Dynamic Range Digital WDR
Image Setting Saturation, Brightness, Contrast, Hue, Sharpness, AGC, White Balance
High Light
Compensation
Support
Day/night Switch Auto / Manual / Scheduled / Alarm trigger
Network
Network Storage NAS, SAMB / CIFS
Alarm trigger
Motion detection, dynamic analysis, tamper alarm, network disconnect, IP address conict, storage full,
storage error
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP,
SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
Security User Authentication, Watermark, IP address ltering, Anonymous access
Standard ONVIF, PSIA, CGI
Interface
Audio Input 1-ch 3.5 mm audio interface, Mic in/Line in. built-in Microphone
Audio Output 1-ch 3.5 mm audio interface
Communication
Interface
1 RJ45 10M/100M/1000M Ethernet port
1 RS-485 interface (-S)
Alarm Input 1
Alarm Output 1
On-board storage Built-in Micro SD/SDXC slot, up to 64 GB
General
Operating Conditions
-30 °C – 60 °C (-22 °F – 140 °F)
Humidity 95% or less (non-condensing)
Power Supply DC12V±10% / PoE
Power Consumption Max. 11W
IR range Max. 10m
Protection IEC 60068-2-75 test, Eh, 50J; EN 50102, EN50155, IK10 (-V)
Dimensions
164 x 152.8 x 43.8mm (6.46” x 6.02” x 1.72”)
Weight 1400g
6
Megapixel
PTZ
DS-2CD6362F-I, DS-2CD6362FD-IS
DS-2CD6362F-IV, DS-2CD6362F-IVS
* -S: Audio/Alarm, RS 485 interface optional
* -V: IP66, Vandal-proof optional
Dimensions
Available
models
Accessories
DS-1280ZJ-DM25
Junction box
DS-1281ZJ-DM25
Inclined ceiling mount
DS-1273ZJ-DM25
Wall mount
DS-1271ZJ-DM25
Pendant mount
