User Manual

PRO-AudioExt

HDMI 2.0a Audio Extractor

Made in Taiwan

User‘s Guide

PAGE 1
® PRO-AudioExt HDMI 2.
PAGE 2
PRO-AudioExt 1. Introduction The PRO-AudioExt supports the separation of high quality stereo analog audio and digital S/PDIF (Toslink) audio from the incoming HDMI signal without losing any active audio channels from audio bit-stream . 2. DIP Switch Setting Position PIN#1 PIN#2 PIN#3 PIN#4 OFF[] ON[] OFF[] ON[] OFF ON 1 2 3 4 If setting OFF[] OFF[] EDID-TV OFF[] ON[] EDID-5.
PAGE 3
® 4. Feature • • • • • • • • HDMI 2.0a compliant Supports 4K2K@60 4:4:4 8bits Supports HDR, which is 4K2K@60 4:2:0 10bits HDCP 2.2 compliant Supports CEC bypass Supports audio extraction via stereo & Toslink Supports ARC audio extraction via Toslink HDMI Audio Format: PCM 2/5.1/7.1, Dolby 5.1/7.1, DTS 5.1/7.1 • Optical Audio Format: PCM 2, Dolby 5.1, DTS 5.1 • Stereo Audio Format: PCM 2 5.
