1 of 4

INCLUDES:

• G-Flex™ Variable Speed Technology

• Designed specifically for use with

alternative energy and storage solutions

• Two Line LCD Multilingual Digital

Evolution™ Controller (English/Spanish/

French/Portuguese)

• Electronic Governor

• External Main Circuit Breaker,

System Status & Maintenance

Interval LED Indicators

• GFCI Duplex Outlet

• Sound Attenuated Enclosure

• Flexible Fuel Line Connector

• Composite Mounting Pad

• Protective Base Fascia

• Natural Gas or LP Gas Operation

• 3 Year Limited Warranty

• Capability to be installed within

18" (457 mm) of a building**

Standby Power Rating

Model 006103-0 (Aluminum - Gray) - 15 kW 60 Hz

*Built in the USA using domestic

and foreign parts

15 kW

EcoGen™

Variable Speed Residential Standby Generator

Air-Cooled Gas Engine

FEATURES

¡ INNOVATIVE DESIGN & PROTOTYPE TESTING are key components

of GENERAC’S success in “IMPROVING POWER BY DESIGN.” But it

doesn’t stop there. Total commitment to component testing, reliability

testing, environmental testing, destruction and life testing, plus testing

to applicable CSA, NEMA, EGSA, and other standards, allows you to

choose GENERAC POWER SYSTEMS with the confidence that these

systems will provide superior performance.

G-FLEX VARIABLE SPEED TECHNOLOGY: By utilizing patented variable

speed technology, the generator is capable of running at various RPMs depending

on the electrical demand, resulting in quieter operation, better fuel economy and

produce power at <2% total harmonic distortion for quality power.

¡ EXTENDED RUN CAPABILITY. This innovative oil circulation system

extends the maintenance intervals by an unprecedented 5 times the

industry standard by offering 500 hour maintenance intervals.

¡ TEST CRITERIA:

PROTOTYPE TESTED  NEMA MG1-22 EVALUATION

 SYSTEM TORSIONAL TESTED  MOTOR STARTING ABILITY

¡ SOLID-STATE, FREQUENCY COMPENSATED VOLTAGE REGULATION.

This state-of-the-art power maximizing regulation system is standard on

all Generac models. It provides optimized FAST RESPONSE to changing

load conditions and MAXIMUM MOTOR STARTING CAPABILITY by

electronically torque-matching the surge loads to the engine. Digital

voltage regulation at ±1%.

¡ SINGLE SOURCE SERVICE RESPONSE from Generac’s extensive dealer

network provides parts and service know-how for the entire unit, from the

engine to the smallest electronic component.

¡ PURPOSE BUILT FOR RENEWABLE ENERGY APPLICATIONS.

Designed specifically to interact with off-grid renewable energy

applications, Generac introduces the first generator intended for

alternative energy interaction. Capable of tying into an inverter and

battery storage system to supplement the alternative energy source.

This provides the cleanest running, low emission solution to recharging

house batteries.

** Only if located away from doors, windows and fresh air intakes,

and unless otherwise directed by local codes.

ISO

9001:

2008

Summary of content (4 pages)

PAGE 1
5 kW EcoGen™ 15 kW ® Variable Speed Residential Standby Generator Air-Cooled Gas Engine 1 of 4 INCLUDES: • G-Flex™ Variable Speed Technology • Designed specifically for use with alternative energy and storage solutions • Two Line LCD Multilingual Digital Evolution™ Controller (English/Spanish/ French/Portuguese) • Electronic Governor • External Main Circuit Breaker, System Status & Maintenance Interval LED Indicators • GFCI Duplex Outlet • Sound Attenuated Enclosure • Flexible Fuel Line Connector
PAGE 2
15 kW ® 2 of 4 15 kW features and benefits Engine •Generac (OHVI) design Maximizes engine “breathing” for increased fuel efficiency. Plateau honed cylinder walls and plasma moly rings help the engine run cooler, reducing oil consumption resulting in longer engine life. •“Spiny-lok” cast iron cylinder walls Rigid construction and added durability provide long engine life. •Electronic ignition/spark advance These features combine to assure smooth, quick starting every time.
PAGE 3
15 kW specifications Generator Model Rated Maximum Continuous Power Capacity (LP) Rated Maximum Continuous Power Capacity (NG) Rated Voltage Rated Maximum Continuous Load Current – 240 Volts (LP/NG) Total Harmonic Distortion Main Line Circuit Breaker Phase Number of Rotor Poles Rated AC Frequency Power Factor Battery Requirement (not included) Unit Weight (lb/kg) Dimensions (L x W x H) in/mm Sound output in dB(A) at 23 ft (7 m) with generator operating at normal load** 006103-0 15,000 Watts* 15,000 Watts
PAGE 4
15 kW ® 15 kW available accessories Model # Product Description 005819-0 26R Wet Cell Battery Every standby generator requires a battery to start the system. Generac offers the recommended 26R wet cell battery for use with all air-cooled standby product. 006212-0 Cold Weather Kit If the temperature regularly falls below 32 °F (0 °C), a cold weather kit is required to maintain optimal battery and oil temperatures. Kit consists of battery warmer and oil filter heater with built-in thermostats.
