User Manual

Application Example #3 Appendix A: MS-5210UD
ACM-8RF PN 50362:C 03/21/01
27
The figure below is provided as an application example of using two LED-10s
and two ACM-8RFs. It is not intended to be used as a wiring diagram.
Refer to Figure 13 on page 21, or the appropriate instruction manuals, for
detailed wiring information.
Figure 14 Two LED-10s and Two ACM-8RFs
J6
J6
+ - + -
+
+
-
-
FIRE ANNUNCIATOR
FIRE ANNUNCIATOR
12
OFF
123 45678
O
F
F
12
OFF
12345678
O
F
F
FACP Program Level 3
Address 02 = ‘0’
Address 03 = ‘3’
MS-5210UD
LED-10IM
LED-10 Address ‘01’
LED-10 Address ‘02’
Receive/Transmit
Receive/Transmit
ACM-8RF
Address ‘03’
ACM-8RF
Address ‘03’
Receive/Transmit
Receive Only
acmfapp3.cdr
