Remote Operation, cont’d
MVX 44 / 48 / 84 / 88 VGA Matrix Switchers • Remote Operation4-16
Windows buttons, drop boxes, and trash
The buttons on the right side of the window perform the following
functions:
Power — Unavailable for MVX switcher, because the switcher power
cannot be controlled via software.
Executive mode (front panel security lockout) — Allows you to lock
out front panel operations, except for the view-only mode
functions.
Presets menu — Displays a list of up to 16 presets. You can select a
preset from the list to display it in the window.
Go — Activates the selected preset as the current configuration.
Save as — Allows the current set of ties to be saved as a preset. Enter
the preset number when prompted to do so.
Delete — Allows you to delete a selected preset.
Changes – Take — Allows you to apply any changes made to the
displayed configuration.
Changes – Cancel — Returns to the previous screen, undoing any
changes you have made.
Trash can — Drag and drop from an input or output button to the
trash can to unmake all ties associated with that input or output.
Windows menus
File menu —
Save matrix settings as — Saves a complete set of up
to 16 presets, plus the last active setting
(preset #0), to a file. Saved settings include
audio gain settings (if specified), assigned
icons, and icon captions.
Restore matrix settings from — Loads and activates
a previously saved setting file.
Save this-session’s settings — Saves a complete set of up to 16 presets, plus
the last active setting (preset #0), to overwrite the current file. Saved
settings include audio gain settings (if specified), assigned icons, and
icon captions.
Restore last-session’s settings — Loads the icons and icon captions that were
saved during the last session. If you saved the previous session’s
changes to disk the last time you exited the program, the ties from that
session are also loaded.
Select printer — Selects the target printer.
Print tie map — Prints the tie set that is displayed on the screen.
Exit — Closes the Extron Matrix Switchers Control Program.
