x7722271404 / x772000164 Operator’s Manual Burn Hazard The muffler or catalytic muffler and surrounding cover may become extremely hot. Always keep clear of exhaust and muffler area, otherwise serious personal injury may occur. The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm.
TABLE OF CONTENTS SRM-2620 TABLE OF CONTENTS Table of Contents ........................................................................................ 2 Introduction ................................................................................................. 4 The Operator’s Manual ........................................................................ 4 The Safety Manual............................................................................... 4 Servicing Information .........................
SRM-2620 TABLE OF CONTENTS Storage ..................................................................................................... Long Term Storage (Over 30 Days)................................................... Specifications ........................................................................................... Product Registration ................................................................................. Notes .........................................................................
INTRODUCTION SRM-2620 INTRODUCTION Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job dependability. Read and understand this manual and the SAFETY MANUAL. You will find both easy to use and full of helpful operating tips and SAFETY messages. The Operator’s Manual Keep it in a safe place for future reference. Contains specifications and information for safety, operation, maintenance, storage and assembly specific to this product.
SRM-2620 SAFETY Service Echo Consumer Product Support If you require assistance or have questions concerning the application, operation or maintenance of this product you may call the ECHO Consumer Product Support Department at 1-800-673-1558 from 8:00 am to 5:00 pm (Central Standard Time) Monday through Friday. Before calling, please know the model and serial number of your unit.
SAFETY SRM-2620 The safety alert symbol accompanied by the word “DANGER” calls attention to an act or condition which WILL lead to serious personal injury or death if not avoided. The safety alert symbol accompanied by the word “WARNING” calls attention to an act or condition which CAN lead to serious personal injury or death if not avoided. The safety alert symbol accompanied by the word “CAUTION” calls attention to an act or condition which may lead to minor or moderate personal injury if not avoided.
SRM-2620 SAFETY Symbol Description Hot Surface Symbol Description Fuel and Oil Mixture ENGLISH AVOID KICKOUT Keep Bystanders At Least 15 meters (50 feet) Away. Beware Thrown Objects Wear Eye Protection DO NOT Allow Flames or Sparks Near Fuel Ignition ON / OFF DO NOT Smoke Near Fuel Primer Bulb Choke Control “RUN” Position (Choke Open) Choke Control “COLD START” Position (Choke Closed) Keep Feet Away From Blade Rotating Cutting Attachment Keep Bystanders and Helpers Away 15 m (50 ft.
SAFETY SRM-2620 Personal Condition and Safety Equipment Users of this product risk injury to themselves and others if the unit is used improperly and/or safety precautions are not followed. Proper clothing and safety gear must be worn when operating unit. Physical Condition Your judgment and physical dexterity may not be good: • If you are tired or sick. • If you are taking medication. • If you have taken alcohol or drugs. Operate unit only if you are physically and mentally well.
SRM-2620 SAFETY Hand Protection Wear sturdy, no-slip, rubber work gloves to improve your grip on the handles. Gloves also provide protection against cuts and scratches, cold environments, and reduce the transmission of machine vibration to your hands. ENGLISH Hearing/Ear Protection ECHO recommends wearing hearing protection whenever unit is used.
SAFETY SRM-2620 The components of this machine generate an electromagnetic field during operation, which may interfere with some pacemakers. To reduce the risk of serious or fatal injury, persons with pacemakers should consult with their physician and the pacemaker manufacturer before operating this machine. In the absence of such information, ECHO does not recommend the use of this machine by anyone who has a pacemaker.
SRM-2620 SAFETY Repetitive Stress Injuries (RSI) ENGLISH It is believed that overusing the muscles and tendons of the fingers, hands, arms, and shoulders may cause soreness, swelling, numbness, weakness, and extreme pain in those areas. Certain repetitive hand activities may put you at a high risk for developing a Repetitive Stress Injury (RSI). An extreme RSI condition is Carpal Tunnel Syndrome (CTS), which could occur when your wrist swells and squeezes a vital nerve that runs through the area.
SAFETY SRM-2620 Read the Manuals • Provide all users of this equipment with the Operator’s Manual and Safety Manual for instructions on Safe Operation. Clear the Work Area • Spectators and fellow workers must be warned, and children and animals prevented from coming nearer than 15 m (50 ft.) while the unit is in use. Keep a Firm Grip • Always hold throttle handle and support handle with thumbs and fingers tightly encircling the handles. Keep a Solid Stance • Maintain footing and balance at all times.
SRM-2620 EMISSION CONTROL • Check that handle and harness (if included) are adjusted for safe, comfortable operation. See Assembly Section for proper adjustment. Periodically Check fuel system (fuel lines, vent, grommet, fuel tank, and fuel cap) for leaks especially if the unit is dropped. If damage or leaks are found, do not use unit, otherwise serious personal injury or property damage may occur. Have unit repaired by an authorized servicing dealer before using.
EMISSION CONTROL SRM-2620 An Emission Control Label is located on the engine. (This is an EXAMPLE ONLY, information on label varies by engine FAMILY). Product Emission Durability (Emission Compliance Period) The 50 or 300 hour emission compliance period is the time span selected by the manufacturer certifying the engine emissions output meets applicable emissions regulations, provided that approved maintenance procedures are followed as listed in the Maintenance Section of this manual.
SRM-2620 DESCRIPTION DESCRIPTION Locate the safety decal(s) on your unit. Make sure the decal(s) is legible and that you understand and follow the instructions on it. If a decal cannot be read, a new one can be ordered from your ECHO dealer. 11 ENGLISH 19 7 12 13 18 6 8 5 8 9 17 14 4 16 3 15 2 10 1 2 10 X7502341700 © 10/2016 ECHO Inc.
DESCRIPTION SRM-2620 Shaft Label Hot Label 1. POWER HEAD - Includes the Engine, Clutch, Fuel System, Ignition System and Recoil Starter. 2. THROTTLE HANDLE - FOR RIGHT HAND - Contains Stop Switch, Throttle Lockout, and Throttle Trigger. 3. THROTTLE TRIGGER LOCKOUT - This lever must be held during starting. Operation of the throttle trigger is prevented unless throttle trigger lockout lever is engaged. 4. STOP SWITCH - “SLIDE SWITCH” mounted on top of the Throttle Handle.
SRM-2620 DESCRIPTION 13. RECOIL STARTER HANDLE - Pull handle slowly until starter engages, then quickly and firmly. When engine starts, return handle slowly. DO NOT let handle snap back or damage to unit will occur. 15. FUEL TANK - Contains fuel and fuel filter. 16. FUEL TANK CAP - Covers and seals fuel tank opening. 17. CHOKE - The choke control is located at the rear of the air cleaner housing. Move choke lever to COLD START ( ) to close choke for cold start.
CONTENTS SRM-2620 CONTENTS The ECHO product you purchased has been factory pre-assembled for your convenience. Due to packaging restrictions, some assembly may be necessary. After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts.
SRM-2620 ASSEMBLY ASSEMBLY Support Handle Installation 1. ENGLISH Note: Label shows minimum spacing for support handle location. If necessary, position support handle for comfortable operation and securely tighten screws. MINIMUM SPACING OPERATION Moving parts can amputate fingers or cause severe injuries. Keep hands, clothing and loose objects away from all openings.
OPERATION SRM-2620 Operation With Blades Blade use DEMANDS specific Brush Cutter configuration. Operation without specified shield, barrier bar or U-handle, and harness can result in serious personal injury. Follow installation instructions.
SRM-2620 OPERATION Blade Selection Plastic/Nylon Grass/Weed Blades may be used where ever the nylon line head is used. DO NOT use this blade for heavy weeds or brush! 8 Tooth Weed/Grass Blade is designed for grass, garden debris and thick weeds up to 19 mm (3/4 in.) diameter. DO NOT use this blade for brush or heavy woody growth. 80 Tooth Brush Blade is designed for cutting brush and woody growth up to 13 mm (1/2 in.) diameter.
OPERATION SRM-2620 During blade operation, the same fatigue reduction is achieved. Safety to the operator is also enhanced by reducing the possibility of blade contact with the operator's hands and feet by restricting trimmer movement. Fuel Diesel fuels and alternative fuels, such as E-15 (15% ethanol), E85 (85% ethanol) or any fuels not meeting ECHO requirements are NOT approved for use in ECHO 2-stroke gasoline engines.
SRM-2620 OPERATION Handling Fuel Mixing Instructions 1. Fill an approved fuel container with half of the required amount of gasoline. 2. Add the proper amount of 2-stroke oil to gasoline. 3. Close container and shake to mix oil with gasoline. 4. Add remaining gasoline, close fuel container, and remix. Fuel to Oil Mix – 50:1 Ratio US Metric Gas Oil Gas Oil Gallons Oz. Liter CC. 1 2.6 5 100 2 5.2 10 200 5 13 25 500 Spilled fuel is a leading cause of hydrocarbon emissions.
OPERATION SRM-2620 • DO NOT store a unit with fuel in its tank. Leaks can occur. Return unused fuel to an approved fuel storage container. Storage - Fuel storage laws vary by locality. Contact your local government for the laws affecting your area. As a precaution, store fuel in an approved, airtight container. Store in a well-ventilated, unoccupied building, away from sparks and flames. Stored fuel ages.
SRM-2620 2. Choke Move choke lever (B) to COLD START ( ) position. Purge Bulb Pump purge bulb (C) until fuel is visible and flows freely in the clear fuel tank return line. Pump bulb an additional 4 or 5 times. 4. B ENGLISH 3. OPERATION C Recoil Starter Lay the unit on a flat area and keep movable attachment parts clear of all obstacles. Firmly grasp throttle handle and throttle trigger lockout with left hand and fully depress throttle trigger to wide open position.
OPERATION SRM-2620 The attachment should not move at idle, otherwise serious personal injury may result. Note: If attachment moves, readjust carburetor according to “Carburetor Adjustment” instructions in this manual or see your ECHO Dealer. 1. Stop Switch A Move stop switch button (A) forward away from the STOP position. 2. Purge Bulb Pump purge bulb (C) until fuel is visible in the “Clear” fuel return line. Pump bulb an additional 4 or 5 times. B C 3.
SRM-2620 MAINTENANCE Stopping Engine 1. Throttle A 2. ENGLISH Release throttle trigger and allow engine to return to idle before shutting off engine. Stop Switch Move stop switch button (A) backward to STOP position. If engine does not stop when stop switch is moved to STOP position, close choke - COLD START position - to stall engine. Have your ECHO dealer repair stop switch before using unit again. MAINTENANCE Moving parts can amputate fingers or cause severe injuries.
MAINTENANCE SRM-2620 Click HERE or go to http://www.echo-usa.com/products/maintenance-kit for information on Maintenance Kits.
SRM-2620 MAINTENANCE * Replacement is recommended based on the finding of damage or wear during inspection ENGLISH Air Filter Level 1 Parts Required: Tune Up Kit. 1. Close choke (COLD START [ ] position). This prevents dirt from entering the carburetor throat when the air filter is removed. Brush accumulated dirt from air cleaner area. 2. Remove air filter cover. Brush dirt from inside cover.
MAINTENANCE SRM-2620 Assure air filter is assembled with pleats oriented vertically. Fuel Filter Level 1. Parts Required: Tune Up Kit. Fuel is VERY flammable. Use extreme care when mixing, storing or handling, or serious personal injury may result. 1. Use a clean rag to remove loose dirt from around fuel cap and empty fuel tank. 2. Pull the fuel filter from the fuel tank. Do not damage fuel line while removing fuel filter from tank. 3. Remove the filter from the line and install the new filter.
SRM-2620 MAINTENANCE Spark Plug Level 2. Parts Required: Tune Up Kit. 1. Remove spark plug and check for fouling, worn and rounded center electrode. 2. Clean the plug or replace with a new one. DO NOT sand blast to clean. Remaining sand will damage engine. 3. Adjust spark plug gap by bending outer electrode. 4. Tighten spark plug to 102-153 kgf•cm (89-133 in•lbf). 0.6 mm (0.026 in.) Cooling System Level 2. Parts Required: None if you are careful.
MAINTENANCE SRM-2620 Overheating and engine seizure can occur when: • Air intakes are blocked, preventing cooling air from reaching the cylinder. • Dust and grass build up on the outside of the cylinder. This build up insulates the engine and prevents the heat from leaving. Removal of cooling passage blockages or cleaning of cooling fins is considered “Normal Maintenance.” Any failure attributed to lack of maintenance is not warranted. 1. Remove spark plug lead. 2. Remove muffler cover (A). 3.
SRM-2620 MAINTENANCE Remove spark plug lead. 2. Remove muffler cover (B). 3. Place piston at Top Dead Center (TDC) to prevent carbon/dirt from entering cylinder. 4. Remove spark arrestor screen cover (C), gasket (E), and screen (F), from muffler body. 5. Clean carbon deposits from muffler components. ENGLISH 1. F Note: When cleaning carbon deposit, be careful not to damage the catalytic element inside muffler. 6. Replace screen if it is cracked, plugged, or has holes burned through. 7.
MAINTENANCE SRM-2620 4. Inspect heat shield, and replace if damaged. 5. Install heat shield and muffler. 6. Tighten muffler mounting bolts (or nuts) to 90-110 kgf•cm (80-95 in•lbf). 7. Install muffler cover and attach spark plug lead. 8. Start engine, and warm to operating temperature. 9. Stop engine, and re-tighten mounting bolts (or nuts) to specifications. Carburetor Adjustment Level 2.
SRM-2620 1. MAINTENANCE A ENGLISH Check idle speed and reset if necessary. If a tachometer is available, idle speed screw (A) should be set to the specifications found on “Specifications” page of this manual. Turn idle screw (A) clockwise to increase idle speed; counterclockwise to decrease idle speed. When carburetor adjustment is completed, the cutting attachment should not move at idle, otherwise serious personal injury may result. Lubrication Level 1. Parts Required: Lithium Based Grease.
MAINTENANCE SRM-2620 Nylon Line Head Disassembly Instructions Note: For normal use, Speed Feed® head disassembly is not necessary. However, if circumstances require disassembly, follow these instructions. 1. 2. Press top of locking tabs (A) on both sides of Speed Feed® head to release cover (B) from eyelet carrier (C). A B Remove cover from eyelet carrier. C Nylon Line Replacement Wear Gloves or personal injury may result: ◆ Cutoff knife is sharp. ◆ Gearcase and surrounding area may be hot. 1.
SRM-2620 Insert one end of trimmer line into an eyelet, and push line equal distance through trimmer head. 4. Hold trimmer head while turning knob clockwise to wind line onto spool until about 13 cm (5 in.) of each line remains exposed. ENGLISH 3. MAINTENANCE Trimmer head is now fully loaded and ready for operation. When the wear indicators located at the bottom of the Speed-Feed® head are worn smooth, or if holes appear, replacement of the cover or the entire Speed-Feed® head is required.
MAINTENANCE SRM-2620 Sharpening Metal Blades Several styles of metal blades are approved for use on the Brush Cutter. The 8-tooth blade can be sharpened during normal maintenance. The clearing blade and 80 tooth blade require professional service. Before sharpening, CLOSELY inspect blade for cracks (look at the bottom of each tooth and the center mounting hole closely), missing teeth and bending. If ANY of these problems are discovered, replace the blade.
SRM-2620 TROUBLESHOOTING TROUBLESHOOTING Problem Engine cranks starts hard/ doesn’t start Check Status Cause Remedy Fuel at carburetor No fuel at carburetor Clean or replace - See your Echo dealer Fuel at cylinder No fuel at cylinder Muffler wet with fuel Fuel strainer clogged - Fuel line clogged Carburetor Carburetor Spark at end of plug wire Spark at plug Air filter See your Echo dealer Fuel Mixture OPEN choke too rich Clean/replace air filter - Adjust carburetor - See your Echo dealer No
STORAGE SRM-2620 ENGINE PROBLEM TROUBLESHOOTING CHART Problem Check Status Cause Remedy Engine does not crank N/A N/A Internal engine problem See your Echo dealer Fuel vapors are extremely flammable and may cause fire and/or explosion. Never test for ignition spark by grounding spark plug near cylinder plug hole, otherwise serious personal injury may result. STORAGE During operation the muffler or catalytic muffler and surrounding cover become hot.
SRM-2620 STORAGE Drain fuel tank completely. Press purge bulb 6-7 times to remove remaining fuel from carburetor then drain the tank again. Close choke, start and run the engine until it stops due to lack of fuel. 7. Allow engine to cool then remove the spark plug and pour 7 cc (1/4 oz.) of fresh, clean, two-stroke engine oil into the cylinder through the spark plug hole. 8. Pull the recoil starter handle 2-3 times to distribute the oil inside the engine. 9.
SPECIFICATIONS SRM-2620 SPECIFICATIONS MODEL SRM-2620 Length w/o cutter head 1799 mm (70.8 in.) Width 273mm (10.7 in.) Height 336mm (13.2 in.) Weight (dry) w/o cutter head 5.1 kg (11.2 lb.) Engine Type Air cooled, two-stroke, single cylinder gasoline engine Bore 34 mm (1.34 in.) Stroke 28 mm (1.10 in.) Displacement 25.4cc (1.55 cu. in.
SRM-2620 SPECIFICATIONS MODEL SRM-2620 Front - loop, Rear handle Shoulder Harness Optional Idle Speed 3,000 RPM Clutch Engagement Speed 4,100 RPM Wide Open Throttle Speed (W.O.T.) 10,300 RPM X7502341700 © 10/2016 ECHO Inc.
PRODUCT REGISTRATION SRM-2620 PRODUCT REGISTRATION Thank you for choosing ECHO Power Equipment Please go to http://www.echo-usa.com/Warranty/Register-Your-ECHO to register your new product on-line. It's FAST and EASY! NOTE: your information will never be sold or misused by ECHO, Inc. Registering your purchase enables us to contact you in the unlikely event of a service update or product recall, and verifies your ownership for warranty consideration.
