Air Brake and EEC Kit Installation Guide for 200i/250i and 200iP/250iP Motorcycle Dynamometers
AIR BRAKE AND EEC KIT
EEC Finger Guards—200iP/250iP
24
4 Secure each EEC finger guard to the drum guard mount using two
1/4-20 x 5/8-inch pan head screws.
Figure 24: Securing the Finger Guards to the Drum Guard Mount
screw
left pit cover plate
finger guard
drum guard mount
