5.4.6 File-Protect Sensor (P/N FD-11389-01)
To remove the file-protect sensor, see Figure 5–9 and proceed as follows:
1. Disconnect the cable from the file-protect sensor .
2. Remove the two screws securing the sensor to the deck plate.
To replace the file-protect sensor, follow the removal procedure in the reverse order. Use
Service Aid 131 (Section 4.5.2.3) to verify that the sensor functions properly.
Figure 5–9: Removing the File-Protect Sensor
