5.4.33 Tape-In-Path Transmitter (P/N 29-28483-01)
To remove the tape-in-path transmitter, refer to Figure 5–35 and proceed as follows:
1. Disconnect the connector from the tape-in-path transmitter .
2. Remove the two screws attaching the tape-in-path transmitter to the deck plate,
then remove the transmitter.
To replace the tape-in-path transmitter, proceed as follows:
1. Perform the removal procedure in reverse order.
2. Check that the sensor functions properly using Service Aid 131 (Section 4.5.2.3).
Figure 5–35: Removing the Tape-in-Path Transmitter
Removal/Replacement Procedures 5–55
