6-08-2003 18:02 Pagina 1 instr uctions 5748010000 DEC 21 Dehumidifier
5748010000 6-08-2003 18:02 Pagina 2 Control Panel Air filter Lifting handle Air outlet grille Intake grille Condensate collection tank Accessory condensate drain hose (2 m.
5748010000 6-08-2003 18:02 Pagina 3 Thank you for choosing this dehumidifier. To get the very best out of your dehumidifier it is advisable to read these instructions before using the appliance. By doing so you will obtain optimum results and maximum safety. Electrical connections Before plugging the appliance into the power socket, check that: • The mains power supply corresponds to the power supply indicated on the rating plate. • The power socket and electrical circuit are adequate for the appliance.
5748010000 6-08-2003 18:02 Pagina 4 Controls Tank control system This dehumidifier is fitted with a special device to ensure correct operation. A red indicator light on the control panel comes on to warn the user when: 1. the tank is full empty the tank 2. the tank is missing replace the tank 3. the tank is in the wrong position position the tank correctly 4. in continuous drain: the hose is obstructed or placed too high above the drain spout remove the obstruction.
748010000 6-08-2003 18:02 Pagina 5 How to dehumidify How to dehumidify 1) Plug the appliance into a mains socket. Dehumidifying standby light Humidistat knob Function selector Tank full/ tank missing 2) Check that the “tank full/tank missing” light is off, if not place the tank in the correct position or empty it if it’s necessary.
5748010000 6-08-2003 18:02 Pagina 6 Combined mode, (dehumidifying + heating) 1) Plug the appliance into a mains socket. 2) Check that the “tank full/no tank” warning light is off. 3) Select maximum (combi MAX) or minimum (combi MIN) power level. Consequently the electrical power will be 1030 W or 1530 W.
5748010000 6-08-2003 18:02 Pagina 7 Problem solving Check the following points before calling your Service Centre PROBLEM POSSIBLE CAUSES SOLUTION The dehumidifier doesn’t work for about 3 minutes from turning on • the appliance’s safety device has intervened • wait for 3 minutes The appliance does not work in dehumidifying mode (indicator light off) • the appliance is not plugged in • there is no current • the humidistat is on minimum • the tank is full of water • the tank is incorrectly positio
5748010000 6-08-2003 18:02 Pagina 8 Technical Characteristics DEC21 See rating label “ “ “ yes yes 2 yes no yes 570x360x300mm 4 litres Power supply voltage Absorbed power dehumidifying only Maximum absorbed power Maximum absorbed current Defrosting device Humidistat Fan speeds Air filter Purifying filter Dimensions LxHxD Tank capacity Operating limits: • temperature • relative humidity Heating Dehumidifying Max. 27°C Max.
5748010000 6-08-2003 18:02 Pagina 9 Important • Use this appliance only as described in this instruction manual. As with any electrical appliance, whilst the instructions aim to cover as many eventualities as possible caution and common sense should be applied when operating your appliance. • This appliance is designed to dehumidify domestic rooms and must not be used for other purposes. • Do not use in the vicinity of baths, showers, sinks, swimming pools, etc.
5748010000 6-08-2003 18:02 Pagina 10 Electrical requirements Before using this appliance ensure that the voltage indicated on the product corresponds with the main voltage in your home, if you are in any doubt about your supply contact your local electricity company. The flexible mains lead is supplied connected to a B.S. 1363 fused plug having a fuse of 13 amp capacity.
5748010000 6-08-2003 18:02 Pagina 11 11 Dehumidifier
5748010000 6-08-2003 Dehumidifier 18:02 Pagina 12 12 5748009300/07.
