116 Installing System Components
4
Replace the cooling shroud. See "Installing the Cooling Shroud" on
page 81.
5
Install the optical drive cable. See "Removing the Optical Drive Cable" on
page 99.
6
Close the system. See "Closing the System" on page 67.
7
Reconnect the system and peripherals to their power sources, and turn
them on.
Sideplane Board
Removing the Sideplane Board
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
1
Turn off the system and attached peripherals, and disconnect the system
from the electrical outlet.
2
Open the system. See "Opening the System" on page 67.
3
Remove the SAS controller daughter card. See "Removing a SAS
Controller Daughter Card" on page 87.
4
Remove any cables from the sideplane board.
5
Pressing inward on the sideplane release tabs, lift the sideplane up and
away from the system. See Figure 3-25
