Appendix G: Technical Specificationsxxx | xxx174
Input video
resolution
Standard
640 x 480 @ 60 Hz
800 x 600 @ 75 Hz
960 x 700 @ 75 Hz
1024 x 768 @ 75 Hz
1280 x 1024 @ 75 Hz
1600 x 1200 @ 60 Hz
Widescreen
800 x 500 @ 60 Hz
1024 x 640 @ 60 Hz
1280 x 800 @ 60 Hz
1440 x 900 @ 60 Hz
1680 x 1050 @ 60 Hz
Supported
cabling
4-pair UTP, 45 meters maximum length
Dimensions
Form factor 1U or 0U rack mount
Dimensions 1.72 x 17.00 x 9.20 (Height x Width x Depth)
Weight (without
cables)
1082DS: 6.6 lb (3.0 kg)
2162DS: 7.0 lb (3.2 kg)
4322DS: 7.6 lb (3.4 kg)
SETUP port
Number 1
Protocol RS-232 serial
Connector 8-pin modular (RJ-45)
Local port
