Chassis Information Group 113
Table 5-14. Watchdog Control Settings
Variable Name:
DellWatchControlSettings
NOTE:
The watchdog timer is the mechanism used by a chassis to determine if the
operating system has stopped responding.
Data Type: Integer
Possible Data Values Meaning of Data Value
automaticRebootEnabled(1) Automatic reboot is enabled for this
host.
automaticPowerCycleEnabled(2) Automatic power cycleable is enabled
for this host.
automaticNotificationEnabled(4) Automatic notification is enabled for
this host.
automaticPowerOffEnabled(8) Automatic power off is enabled for
this host.
Table 5-15. Watchdog Timer Capabilities
Variable Name:
DellWatchDogTimerCapabilities
Data Type: Integer
Possible Data Values Meaning of Data Value
type1Capable(1) Watchdog timer can time in intervals from
20–480 seconds.
type2Capable(2) Watchdog timer can time in 30-, 60-, 120-, and
480-second intervals.
type3Capable(4) Watchdog timer can time in 60-second intervals.
