D500018LSTC / D500518LSTC / D510418TC
Vaughn™ Single Handle Tub & Shower
Trim Kit Less Showerhead
5 5/16"
(135mm)
4 5/16"
(109mm)
6 1/16"
(154mm)
2 1/16"
(52mm)
6 11/16"
(170mm)
1 11/16"
(44mm)
5 1/4"
(134mm)
1 9/16"
(
40mm)
1/2-14NPT
1 3/4"~1 13/16"
(44mm~46mm)
1 1/8"~1 13/16"
(29mm~46mm)
5/8"
(
16mm)
3 9/16"
(90mm)
26"
(660mm)
65"~80"
(1651mm~2032mm)
19 11/16"
(500mm)
2 15/16"
(
74mm)
6 11/16"
(170mm)
2 1/16" (52mm)
1 5/8" (41mm)
5 5/8"
(143mm)
5 3/4"
(146mm)
1 3/8" (35mm)
1/2-14NPT
1/2-14NPT
Features/Benets
• Includes Treysta™ Pressure Balance Ceramic Disc Cartridge
• Requires Treysta™ Rough-In Valve, G00GS500 Series (Horizontal Inputs)
or G00GS520 Series (Vertical Inputs)
• Showerhead Sold Separately
• 6” Metal Shower Arm
• Diverter on Tub Spout
• Accommodates Standard, Back-to-Back, and Thin Wall Installations
Available Color/Finishes Standards & Certications Flow Rate
Color Description
cartridge max. flow rate
020406
08
0
PSI
GPM
8
6
4
2
0
Chrome
Please see danze.com or current
price list for available nishes.
Finish is dened by additional sufx.
