Specification

Electrical Division 800.523.3869 I FAX [phone]
Consumer Markets Division 866.572.3776 I FAX [phone]
www.cerrowire.com
A Marmon Wire & Cable
Berkshire Hathaway Company
Rev- 05/2011
23 AWG Solid
Bare Copper
-10 C to +75 C
Fluoropolymer
Insulated
300 Volts
Cat-6 Plenum
23 AWG 4 Pair
Communications
Cable
Communications Cable
APPLICATIONS
UL
®
Listed Type CMP Communications plenum cable. 1000’ length in EZ-Pack Box.
1.2 Gbps, ISDN
CONDUCTORS
2 Solid bare copper conductors twisted together with a varying left-hand lay (LHL).
ASSEMBLY
4 twisted pairs cabled to a left-hand lay. Ripcord runs parallel under jacket.
INSULATION
Fluoropolymer .039 in O.D.
JACKET
0.018” nominal-wall blue or white plenum polyvinyl chloride (PVC); .215 in. OD
Low Smoke
Flame retardant
INDUSTRY STANDARDS / CERTIFICATIONS
UL
®
444, Communications Cable
NFPA 262 Plenum Flame Test (UL910)
UL Listed Type CMP
ETLVeried to TIA-568-B.2-1 Category 6
C (UL) CMP
NEC Article 800
EU RoHS Directive
SURFACE PRINT
Sample: COMTRAN CORP. (01-12345) 23 AWG CMP C(UL)US
ETL VERIFIED TO TIA 568-B.2-1 CATEGORY 6 (MM/YY) RoHS 000002 FT
©2010, Cerrowire LLC
All Rights Reserved
MADE IN USA
2’ Sequential
Footage Markers
Blue or White
Plenum PVC Jacket
UL
®
444, NFPA 262
