Chapter 13 447
SCPI Command Reference
E5061A/E5062A commands
13. SCPI Command
Reference
:STAT:QUES:BLIM:CHAN{1-4}:ENAB
Syntax :STATus:QUEStionable:BLIMit:CHANnel{[1]|2|3|4}:ENABle <numeric>
:STATus:QUEStionable:BLIMit:CHANnel{[1]|2|3|4}:ENABle?
Description Sets the value of the Questionable Bandwidth Limit Channel Status Enable Register of
channel 1 (:CHAN1) to channel 4 (:CHAN4).
Parameters
Note that bit 5 to 15 cannot be set to 1.
Query response {numeric}<newline><^END>
Example of use
10 OUTPUT 717;":STAT:QUES:BLIM:CHAN1:ENAB 16"
20 OUTPUT 717;":STAT:QUES:BLIM:CHAN1:ENAB?"
30 ENTER 717;A
Related commands :STAT:QUES:BLIM:ENAB on page 450
Equivalent key No equivalent key is available on the front panel.
<numeric>
Description Value of the enable register
Range 0 to 65535
Preset value Varies depending on the upper limit setting for channel/trace
number.
Resolution 1
