Chapter 13 423
SCPI Command Reference
E5061A/E5062A commands
13. SCPI Command
Reference
:SENS{1-4}:SEGM:SWE:POIN?
Syntax :SENSe{[1]|2|3|4}:SEGMent:SWEep:POINts?
Description For the segment sweep table of channel 1 (:SENS1) to channel 4 (:SENS4), reads out the
total number of the measurement points of all segments. (Query only)
Query response {numeric}<newline><^END>
Example of use
10 OUTPUT 717;":SENS1:SEGM:SWE:POIN?"
20 ENTER 717;A
Related commands :SENS{1-4}:SEGM:DATA on page 421
Equivalent key No equivalent key is available on the front panel.
:SENS{1-4}:SEGM:SWE:TIME?
Syntax :SENSe{[1]|2|3|4}:SEGMent:SWEep:TIME?
Description For the segment sweep table of channel 1 (:SENS1) to channel 4 (:SENS4), reads out the
total sweep time of all segments. (Query only)
Query response {numeric}<newline><^END>
Example of use
10 OUTPUT 717;":SENS1:SEGM:SWE:TIME?"
20 ENTER 717;A
Related commands :SENS{1-4}:SEGM:DATA on page 421
Equivalent key No equivalent key is available on the front panel.
