404 Chapter 13
SCPI Command Reference
E5061A/E5062A commands
:SENS{1-4}:CORR:COLL:METH:THRU
Syntax :SENSe{[1]|2|3|4}:CORRection:COLLect:METHod[:RESPonse]:THRU <numeric
1>,<numeric 2>
Description For channel 1 (:SENS1) to channel 4 (:SENS4), sets the calibration type to the response
calibration (thru) between the 2 specified ports. (No query)
Parameters
For each parameter, you must specify a different port number. If you specify the same port
number for 2 or more parameters, an error occurs and the command is ignored.
Example of use
10 OUTPUT 717;":SENS1:CORR:COLL:METH:THRU 1,2"
Related commands :SENS{1-4}:CORR:COLL:METH:TYPE? on page 405
Equivalent key
[Cal] - Calibrate - Response (Thru) - Ports
<numeric 1> <numeric 2>
Description Port number Port number
Range 1 to 2 1 to 2
Resolution 1 1
