402 Chapter 13
SCPI Command Reference
E5061A/E5062A commands
:SENS{1-4}:CORR:COLL:METH:OPEN
Syntax :SENSe{[1]|2|3|4}:CORRection:COLLect:METHod[:RESPonse]:OPEN <numeric>
Description For channel 1 (:SENS1) to channel 4 (:SENS4), sets the calibration type to the response
calibration (open) of the specified port. (No query)
Parameters
Example of use
10 OUTPUT 717;":SENS1:CORR:COLL:METH:OPEN 1"
Related commands :SENS{1-4}:CORR:COLL:METH:TYPE? on page 405
Equivalent key
[Cal] - Calibrate - Response (Open) - Port
:SENS{1-4}:CORR:COLL:METH:SHOR
Syntax :SENSe{[1]|2|3|4}:CORRection:COLLect:METHod[:RESPonse]:SHORt <numeric>
Description For channel 1 (:SENS1) to channel 4 (:SENS4), sets the calibration type to the response
calibration (short) of the specified port. (No query)
Parameters
Example of use
10 OUTPUT 717;":SENS1:CORR:COLL:METH:SHOR 1"
Related commands :SENS{1-4}:CORR:COLL:METH:TYPE? on page 405
Equivalent key
[Cal] - Calibrate - Response (Short) - Port
<numeric>
Description Port number
Range 1 to 2
Resolution 1
<numeric>
Description Port number
Range 1 to 2
Resolution 1
