372 Chapter 13
SCPI Command Reference
E5061A/E5062A commands
:SENS{1-4}:BAND
Syntax :SENSe{[1]|2|3|4}:BANDwidth[:RESolution] <numeric>
:SENSe{[1]|2|3|4}:BANDwidth[:RESolution]?
Description Sets the IF bandwidth of channel 1 (:SENS1) to channel 4 (:SENS4).
This command provides the same function as the :SENS{1-4}:BWID command.
Parameters
If the specified parameter is out of the allowable setup range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Query response {numeric}<newline><^END>
Example of use
10 OUTPUT 717;":SENS1:BAND 1E3"
20 OUTPUT 717;":SENS1:BAND?"
30 ENTER 717;A
Related commands :SENS{1-4}:BWID on page 373
Equivalent key
[Avg] - IF Bandwidth
<numeric>
Description IF bandwidth
Range 10 to 30000
Preset value 30000
Unit Hz (hertz)
Resolution In steps of 1 or 3
