362 Chapter 13
SCPI Command Reference
E5061A/E5062A commands
:MMEM:STOR:SEGM
Syntax :MMEMory:STORe:SEGMent <string>
Description Saves the segment sweep table for the active channel (specified with the
:DISP:WIND{1-4}:ACT command) into a file in the CSV format.
Specify the file name with the .csv extension. If you want to specify a file on the floppy
disk drive, you need to add “A:” at the beginning of the file name. When you use directory
names and file name, separate them with “/” (slash) or “\” (backslash).
Notice that, if a file with the specified file name exists, its contents are overwritten. (No
query)
Parameters
Example of use
10 OUTPUT 717;":MMEM:STOR:SEGM ""Test1/Segm01.csv"""
10 OUTPUT 717;":MMEM:STOR:SEGM ""A:Segm01.csv"""
Related commands :MMEM:LOAD:SEGM on page 351
:DISP:WIND{1-4}:ACT on page 318
Equivalent key
[Sweep Setup] - Edit Segment Table - Export to CSV File
<string>
Description File name in which you want to save the segment sweep table
Range 254 characters or less
