SCPI Command Reference
E5061A/E5062A commands
:DISP:WIND{1-4}:TRAC{1-4}:Y:RPOS
Syntax :DISPlay:WINDow{[1]|2|3|4}:TRACe{[1]|2|3|4} :Y[:SCALe]:RPOSition <numeric>
:DISPlay:WINDow{[1]|2|3|4}:TRACe{[1]|2|3|4} :Y[:SCALe]:RPOSition?
Description For trace 1 (:TRAC1) to trace 4 (:TRAC4) of channel 1 (:WIND1) to channel 4 (:WIND4),
specifies a reference graticule line with its number (an integer assigned starting from 0
from the lowest division).
Parameters
If the specified parameter is out of the allowable setup range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Query response {numeric}<newline><^END>
Example of use
10 OUTPUT 717;":DISP:WIND1:TRAC1:Y:RPOS 6"
20 OUTPUT 717;":DISP:WIND1:TRAC1:Y:RPOS?"
30 ENTER 717;A
Related commands :DISP:WIND{1-4}:Y:DIV on page 336
:DISP:WIND{1-4}:TRAC{1-4}:Y:PDIV on page 330
:DISP:WIND{1-4}:TRAC{1-4}:Y:RLEV on page 331
Equivalent key
[Scale] - Reference Position
<numeric>
Description Number of graticule line
Range
0 to the number of divisions
*1
Preset value
5
*2
Resolution 1
*1.Set with the :DISP:WIND{1-4}:Y:DIV commands.
*2.When the data format is “Linear Magnitude” or “SWR,” the preset value is 1.
