Chapter 13 285
SCPI Command Reference
E5061A/E5062A commands
13. SCPI Command
Reference
:CALC{1-4}:PAR{1-4}:DEF
Syntax :CALCulate{[1]|2|3|4}:PARameter{[1]|2|3|4}:DEFine {S11|S21|S12|S22}
:CALCulate{[1]|2|3|4}:PARameter{[1]|2|3|4}:DEFine?
Description Sets the measurement parameter of trace 1 (:PAR1) to trace 4 (:PAR4) of channel 1
(:CALC1) to channel 4 (:CALC4).
Parameters
Query response {S11|S21|S12|S22}<newline><^END>
Example of use
10 OUTPUT 717;":CALC1:PAR1:DEF S21"
20 OUTPUT 717;":CALC1:PAR1:DEF?"
30 ENTER 717;A$
Equivalent key [Meas] - S11|S21|S12|S22
Description
S11 (preset value) Specifies S11.
S21 Specifies S21.
S12 Specifies S12.
S22 Specifies S22.
