Chapter 13 267
SCPI Command Reference
E5061A/E5062A commands
13. SCPI Command
Reference
:CALC{1-4}:MARK{1-10}:DISC
Syntax :CALCulate{[1]|2|3|4}[:SELected]:MARKer{[1]|2|3|4|5|6|7|8|9|10}:DISCrete
{ON|OFF|1|0}
:CALCulate{[1]|2|3|4}[:SELected]:MARKer{[1]|2|3|4|5|6|7|8|9|10}:DISCrete?
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4) (specified with the
:CALC{1-4}:PAR{1-4}:SEL command), turns ON/OFF the discrete mode (mode in which
the marker moves only at the measurement points) with marker 1 (:MARK1) to marker 9
(:MARK9) and reference marker (:MARK10).
Parameters
Query response {1|0}<newline><^END>
Example of use
10 OUTPUT 717;":CALC1:MARK1:DISC OFF"
20 OUTPUT 717;":CALC1:MARK1:DISC?"
30 ENTER 717;A
Equivalent key [Marker Fctn] - Discrete
Description
ON or 1 Turn OFF the discrete mode.
OFF or 0 (preset value) Turns OFF the discrete mode.
