User`s guide

266 Chapter 13
SCPI Command Reference
E5061A/E5062A commands
:CALC{1-4}:MARK{1-10}:BWID:THR
Syntax :CALCulate{[1]|2|3|4}[:SELected]:MARKer{[1]|2|3|4|5|6|7|8|9|10}:BWIDth: THReshold
<numeric>
:CALCulate{[1]|2|3|4}[:SELected]:MARKer{[1]|2|3|4|5|6|7|8|9|10}:BWIDth: THReshold?
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4) (specified with the
:CALC{1-4}:PAR{1-4}:SEL command), sets the bandwidth definition value of marker 1
(:MARK1) to marker 9 (:MARK9) and reference marker (:MARK10).
Parameters
If the specified parameter is out of the allowable setup range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Query response {numeric}<newline><^END>
Example of use
10 OUTPUT 717;":CALC1:MARK1:BWID:THR 6"
20 OUTPUT 717;":CALC1:MARK1:BWID:THR?"
30 ENTER 717;A
Related commands :CALC{1-4}:MARK:BWID on page 243
:CALC{1-4}:PAR{1-4}:SEL on page 286
Equivalent key
[Marker Search] - Bandwidth Value
<numeric>
Description Bandwidth definition value
Range -5E8 to 5E8
Preset value -3
Unit Varies depending on the data format as follows:
Logarithmic Magnitude: dB (decibel)
Phase, Expand Phase, Positive Phase: ° (degree)
Group Delay: s (second)
Others: No unit
