User's Manual

Windows 98SE
Windows ME
Windows 2000/NT
Windows XP
Please do not use this product in ashy, wet, or oily environments. Failure
to do so may shorten the life of this product and may cause bodily harm.
Please keep this product as far away from Radio Frequency
interruption areas as possible.
This is not an outdoor product. Exposing this product to the elements
may cause damages to the product and bodily harm to its users.
Please do not use petroleum, benzene or thinner-based solution to
clean this product.
Laser Mouse
International standards and safety. This Laser device complies with
International Standard IEC 60825-1:2001-08, Class 1 Laser Product,
and also complies with 21 CFR1040.10 and 1040.11, except for
deviations pursuant to Laser Notice No.50, dated July 26, 2001:1)
Emission of a parallel beam of infrared user-invisible light: 2) Maximum
Power of 716 microwatts CW, wavelength range 832-865 nanometers;
3) Operating temperature between 0 ( 32 ) to 40 ( 104 ).
CAUTION: This Laser device has no serviceable parts. Use of controls
or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
Safety and Usage Guidelines
1) Do not point infrared beam at eye.
2) In the absence of proper operation and if customer-initiated
troubleshooting is unsuccessful, switch off device and call technical
support.
3) Do not disassemble your product or expose it to liquid, humidity,
moisture, or temperatures outside the specified operating range of 0
( 32 ) to 40 ( 104 ). 4) If you product is exposed to out-of-range
temperatures, Switch it off and allow the temperature to return to the
normal operating range.
B. Setting up the Keyboard and Mouse
A. Setting up the Dongle Receiver
1.
Plug the dongle receiver (FIG. 3) into an available
USB
2. Wait for Windows to install drivers for the dongle
receiver, keyboard and mouse.
3. When the dongle receiver has been properly initialized,
its LED light will stay alit.
Installation Procedure
Before installing this product please make sure you have
one available USB port reserved for the dongle receiver.
Dimensions: L105 x W55.5 x H35.5 mm
Weight: 80.7 +/- 25g (with Battery)
Key Number: 3 Keys
(Wheel button on middle button)
Battery: 2 x AAA batteries
Battery Life: 1 Month (Base on average usage)
Channel: 78 Channels
ID: Unique ID for mouse
Radio Frequency: 2.4 GHz
Dimensions: L70xW22.7xH12.3mm
Weight : 10.9g +/-25g
Interface: USB 1.1
Dimensions: 430 x 162x 20 mm
Weight: 620+/- 20g (with Battery)
Key Number: 104 Keys(By language)
Battery: 2 x AAA batteries
Battery Life: 3 Month (Base on average usage)
Channel: 78 Channels automatically switch.
ID: unique ID for each keyboard
Radio Frequency: 2.4 GHz
Hot Keys : previous page, next page, WWW home,
stop, refresh, my favorite, search, e-mail, mute,
previous, play/pause, next, stop, volume down,
volume up, wake up, sleep, power
Warning
Please be careful when resetting the ID's for the keyboard,
mouse and dongle receiver. Objects with a sharp point may
break and leave behind shards.
Battery Low
3. We recommend using alkaline batteries for the keyboard.
4.You may need to reset the ID's after replacing new
batteries for the keyboard and mouse.
User Manual
Warning
4
5 7
862
1 3
Introduction
Wireless Keyboard x 1
Wireless Laser Mouse x 1
USB 2.4GHz dongle receiver x 1
Installation CD x 1
Manual x 1
Alkaline batteries x4
( 2 AAA for keyboard, 2 AAA for Mouse)
Thank you for purchasing our cordless keyboard
and Laser mouse. For your own safety, please read
this manual thoroughly before using this product.
After you have read this manual, please keep it in
Place for reference when necessary.
The following items are included in the package.
Please make sure all items are accounted for as you
open the package. If there was any i tem missing or
damaged, please contact the store where the
product was purchased or our support center.
Contents in the package
Specifications
Keyboard
Mouse
Dongle Receiver
port.
Any malfunction, damage or personal injury caused by the malfunctioning or
damage of the user's personal computer or misuse of this product.
Do not dismantle, change or modify this product in any way.
Warning
WAKE SLEEP POWER
Batt.Low
1. Low-Battery is indicated by the illumination of the
keyboard LED indicator "Batt.Low". Please replace
the battery when the LED lights up.
2. Low-Battery is indicated by the illumination of the
Mouse Scroll. Please replace the battery when the
LED lights up.
ADE-AD2
OS support
System requirements
IBM or compatible PC
Windows Operating System
Pentium-equivalent processor or above
At least 10MB hard disk space
One available USB port
1. Open the battery compartment covers of the
keyboard & mouse(FIG.1) (FIG.2) and insert the
batteries. Make sure they are properly installed.
2. Replace the battery compartment covers.
3. Usually the keyboard and mouse have been set up in
the factory. If the system cannot recognize the
keyboard and mouse, please follow step 4~7 to bind
keyboard and mouse.
4. Move the keyboard and mouse close to the receiver
(within 30 cm).
5. Press the receiver ID button (FIG.3), then press the
keyboard ID button (FIG.1).
6. Press the receiver ID button again, then press the
mouse Reset button (FIG.2).The system will
automatically recognize the Mouse.
7. The LED indicator on the receiver will turn green
when the keyboard and mouse are connected and
working properly.
This device complies with part 15 of the FCC rules. Operation is subject to the 
following two conditions
(1)•This device may not cause harmful interference and 
(2)•This device must accept any interference received, including interference that 
may cause undesired operation 

You are cautioned that changes or modifications not expressly approved by the 
party responsible for compliance could void your authority to operate the 
equipment. 
1.•This transmitter must not be co-located or operating in conjunction with any 
other antenna or transmitter.
This equipment has been tested and found to comply with the limits for 
a class B digital device, pursuant to part 15 of the FCC rules. These 
limits are designed to provide to provide reasonable protection against 
harmful interference in a residential installation. This equipment 
generates, uses and can radiate radio frequency energy and, if not 
installed and used in accordance with the installation. , May cause 
harmful interference to radio communication. However, there is no 
guarantee that interference
Will not occur in a particular installation. if this equipment does cause 
harmful interference to radio or television reception, which can be 
determined by turning the equipment off and on, the user is encouraged 
to try to correct the interference by one or more of the following 
measures:
-Reorient or relocate the receiving antenna
-Increase the separation between the equipment and receiver
-Connect the equipment into an outlet on a circuit different from that to 
which the receiver is connected
Consult the dealer or an experienced radio / TV technician for help
RF- 726KLP ZI PPY
