Installation and Operating Guide | Warranty Model Number | DVT216 (Speakers: FE-5620TE/FE-5620WE) | DVD Home Cinema System © Copyright 2002, Zenith Electronics Corporation
Safety Precautions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS IN THIS OWNER’S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE. This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following procedures for installation, use, and servicing. This unit does not contain any parts that can be repaired by the user.
Table of Contents Introduction Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . 2 Important Safety Instructions . . . . . . . . . . . . . . . . . 3 Before Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6 Playable Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Notes on Discs . . . . . . . . . . . . . . . . . . . . . . . . . . 6 About Symbols . . . . . . . . . . . . . . . . . . . . . .
Before Use Title (DVD only) The main film content or accompanying feature content or additional feature content, or music album. Each title is assigned a title reference number enabling you to locate it easily. DVD (8 cm / 12 cm disc) Audio CD (8 cm / 12 cm disc) In addition, this unit can play a CD-R or CD-RW that contains audio titles or MP3 files. otes – Depending on the conditions of the recording equipment or the CD-R/RW disc itself, some CD-R/RW discs cannot be played on the unit.
Before Use (Cont’d) Precautions Notes on Discs Handling the unit Handling discs Shipping the unit The original shipping carton and packing materials come in handy. For maximum protection, re-pack the unit as it was originally packed at the factory. Do not touch the playback side of the disc. Hold the disc by the edges so that fingerprints will not get on the surface. Do not stick paper or tape on the disc.
Front Panel and Display Window INTRODUCTION SKIP/SEARCH (TUNING/SKIP) buttons STOP (MEMORY/CLEAR) button PAUSE button PLAY button OPEN/CLOSE button ENTER button VOLUME control MONO/STEREO button HEADPHONE Jack FM/AM button FUNCTION button POWER button and indicator Sound mode indicator TUNED indicator Repeat playback mode indicators SLEEP indicator PROGRAM indicator Chapter/Track number indicator STEREO indicator MUTE indicator Title number indicator PLAY/PAUSE indicator Angle icon indicator Disc
Remote Control Buttons MUTE buttons FM/AM buttons POWER buttons VIDEO 1-2 buttons CD/DVD buttons TEST TONE buttons OPEN/CLOSE buttons • LEVEL buttons • DELAY buttons BY-PASS buttons NUMERICAL buttons SOUND MODE buttons DOLBY PROLOGIC II buttons • • • • REPEAT buttons MARKER buttons SEARCH buttons SLOW SCAN(+/-) buttons PROGRAM buttons SLEEP buttons CLEAR buttons REPEAT A-B buttons VOLUME (+/-) buttons MENU buttons Use the MENU button to display the menu screen included on DVD video discs.
Rear Panel Overview FM 300Ω Antenna Connector INTRODUCTION AM Antenna Connectors VIDEO 1 (Input/Output) Connectors VIDEO 2 (Input) Connectors COMPONENT VIDEO OUT/PROGRESSIVE SCAN (Y Pb Pr) Connectors WOOFER OUT Jack SPEAKER Connectors POWER CORD Plug into a 120 Volt AC 60Hz Outlet only. S-VIDEO OUT Jack VIDEO OUT SELECTOR Switch Refer to explanation below**. VIDEO SELECTOR Switch Refer to explanation below*.
Connections S-Video connection TV Connections 1 Rear of TV S-VIDEO INPUT Pr Pb VIDEO INPUT AUDIO INPUT COMPONENT VIDEO INPUT Y L R L Connect the S-VIDEO OUT jack on the DVD Receiver to the S-Video in jack on the TV using an optional S-Video cable (S). the Left and Right AUDIO OUT jacks of 2 Connect the DVD Receiver to the audio left/right in jacks on the TV (A) using the supplied audio cables.
Connections (Cont’d) Optional Equipment Connections Connect Connect Connect Connect a TV (Monitor) to the MONITOR OUT or S-VIDEO OUT connector. a VCR to the VIDEO 1 jacks. an additional VCR to the VIDEO 2 jacks. the optical output of DVD Receiver (or Digital Device etc) to the OPTICAL IN connector.
Connections (Cont’d) Speaker System Connections Connect the speakers using the supplied speaker cords by matching the colors of the terminals and those of the cords. To obtain the best possible surround sound, adjust the speaker parameters (distance, level, etc.). otes Be sure to match the speaker cord to the appropriate terminal on the components: + to + and – to –. If the cords are reversed, the sound will be distorted and lack bass.
Before Operation Allows you to enjoy 5.1(or 6) discrete channels of high quality digital audio from DTS program sources bearing the trademark such as discs, DVD and compact discs, etc. DTS Digital Surround delivers up to 6 channels of transparent audio(which means identical to the original masters) and results in exceptional clarity throughout a true 360 degree sound field. The term DTS is a trademark of DTS Technology, LLC. Manufactured under license from DTS Technology, LLC.
Before Operation (Cont’d) Sound Mode (Except AM) ote You can enjoy surround sound simply by selecting one of the pre-programmed sound fields according to the program you want to listen to. When you play sound tracks with 96kHz sampling frequency, the output signals will be converted to 48kHz (sampling frequency).
Before Operation (Cont’d) Speaker Sound Delay Time Setting Center delay time setting In Dolby Digital or Dolby Pro Logic mode it is assumed that the distance from the listener to each of the speakers is equal. If not, then set the delay times of the center or rear speakers so that the sound will be heard simultaneously by the listener. The interval from the speakers to the listener.
Before Operation (Cont’d) or to change the setting of an item. 3 Press The number buttons can be also be used for setting numbers (e.g., title number). For some functions, Caution: Before using the remote control, press the DVD or TV button to select the device to be operated. press ENTER to execute the setting. Temporary Feedback Field Icons General Explanation This manual gives the basic instructions for operating the DVD Receiver.
Before Operation (Cont’d) Picture You can set your own Personal Preferences on the player. Initial Settings General Operation 1 Press SETUP. The setup menu appears. TV Aspect DVD 4:3 Letterbox: Select when a standard 4:3 TV is connected. Displays theatrical images with masking bars above and below the picture. 4:3 Panscan: Select when a standard 4:3 TV is connected. Displays pictures cropped to fill your TV screen. Either sides of the picture are cut off.
Before Operation (Cont’d) Parental Control Country Code Rating Enter the code of a country/area whose standards were used to rate the DVD video disc, referring to the list (See “Country Code List”, page 30.). DVD Movies on DVDs may contain scenes not suitable for children. Therefore, discs may contain Parental Control information that applies to the complete disc or to certain scenes on the disc.
Presetting Radio Stations Listening to the Radio You can preset 30 stations for FM and AM. Before tuning, make sure that you have turned down the volume to the minimum. Preset radio stations in the DVD receiver’s memory first (see “Presetting radio stations” on the left side). 1 Press FUNCTION on the front panel repeatedly or FM/AM on the remote control until FM or AM appear in the display window. 1 Press FM/AM until AM or FM appears in the display window. The last received station is tuned in.
Operation with Radio (Cont’d) Sleep Timer Setting Selecting Input Source You can set the DVD receiver to turn off automatically at a specified time. You can use VCRs or other units connected to the VIDEO1, VIDEO2 connectors or Optical connector. Refer to the owner’s manual supplied with the unit for further information on the operation. Press VIDEO1 or VIDEO2 repeatedly on the remote control to select the desired input source.
Operation with DVD Getting to play General Features DVD Switch on the TV and select the AV input source connected to the DVD receiver. When you want to enjoy the sound of discs or from the audio system, turn on the audio system and select the input source connected to the DVD receiver. Press OPEN/CLOSE to open the disc tray. 1 your chosen disc in the tray, with the label 2 Load facing up. When a double-sided DVD is inserted, make sure the side you want to play is facing up.
Operation with DVD General Features (cont’d) Still Picture and Frame-by-Frame Playback DVD Repeat A-B A * A B DVD OFF To repeat a sequence in a title: 1 Press PAUSE during playback. The player will now go into PAUSE mode. 2 You can advance the picture frame by frame by pressing PAUSE repeatedly on the remote control. 1 Press REPEAT A-B at your chosen starting point. Search 3 To cancel the sequence, press REPEAT A-B. DVD 1 Press and hold SKIP . or > for about two seconds during playback.
Operation with DVD General Features (cont’d) Special DVD Features Zoom Checking the contents of DVD Video discs: Menus The Zoom function allows you to enlarge the video image and to move through the enlarged image. 1 Press ZOOM during playback or still playback to activate the Zoom function. If you press ZOOM repeatedly, the magnification level increases up to six times. 2 Use the zoomed picture. buttons to move through the 3 Press CLEAR to resume normal playback or return to the paused image.
Operation with Audio CD and MP3 Disc Playing an Audio CD and MP3 disc Search The DVD Receiver can play MP3 format recordings on CD-ROM, CD-R or CD-RW discs. Before playing MP3 recordings, read the notes of MP3 Recordings on page 26. 1 Press and hold SKIP . or > for about two seconds during playback. Insert a disc and close the tray. The menu appears on the TV screen. 1 CD Program MP3 Program TRACK 1 TRACK 1.MP3 TRACK 2 TRACK 2.MP3 TRACK 3 TRACK 3.MP3 TRACK 4 TRACK 4.MP3 TRACK 5 TRACK 5.
Programmed Playback CD MP3 Programmed Playback with Audio CD Repeat Programmed Tracks and MP3 Disc Program allows you to store your favorite tracks for a particular disc in the player memory. To repeat the track currently playing, press REPEAT. Program can contain 32 tracks (Audio CD) or 60 tracks (MP3 disc). 1 Insert the disc and close the tray. PROGRAM during playback or in the stop 2 Press mode to enter the Program Edit mode. The menu is displayed on the TV screen.
Additional Information Last Condition Memory DVD CD Notes on MP3 Discs About MP3 This player memorizes the last condition for the last disc you have watched. Settings remain in memory even if you remove the disc from the player or switch off the player. If you load a disc that has its settings memorized, the latest stop position is automatically recalled. otes – Settings are stored in memory for use any time.
Troubleshooting Check the following guide for the possible cause of a problem before contacting service. Cause Correction • The power cord is disconnected. • Plug the power cord into the wall outlet securely. The power is on, but the DVD receiver does not work. • No disc is inserted. • Insert a disc. (Check that the DVD or, audio CD indicator in the DVD display is lit.) No picture. • The TV is not set to receive DVD signal output.
Troubleshooting (Cont’d) Symptom Recording is not possible Radio stations cannot be tuned in. Cause Correction • The components are connected incorrectly. • Connect the components correctly. • The source is selected incorrectly. • Select the source with FUNCTION button (CD/DVD, VIDEO 1, VIDEO 2 or Tuner). • The antenna is positioned or connected poorly. • Connect the antenna securely. • Adjust the antennas and connect an external antenna if necessary. The remote control does not work properly.
Language Code List Code Language Code Language Code Language Code Language 6565 Afar 7079 Faroese 7678 Lingala 8375 Slovak 6566 Abkhazian 7082 French 7679 Laothian 8376 Slovenian 6570 Afrikaans 7089 Frisian 7684 Lithuanian 8377 Samoan 6577 Ameharic 7165 Irish 7686 Latvian, Lettish 8378 Shona 6582 Arabic 7168 Scots Gaelic 7771 Malagasy 8379 Somali 6583 Assamese 7176 Galician 7773 Maori 8381 Albanian 6588 Aymara 7178 Guarani 7775 Macedonian 8382
Country Code List Enter the appropriate code number for the initial setting “Country Code” (See page 18).
AM (MW) FM Component video output [Supplied Accessories] [Speakers] [Amplifier] [Tuner] [Video] [CD/DVD] [General] Power supply Power consumption Mass External dimensions (W x H x D) Operating conditions Operating humidity Laser Signal system Frequency response (audio) Signal-to-noise ratio (audio) Dynamic range (audio) Harmonic distortion (audio) Video input Video output S-video output Tuning Range Intermediate Frequency Signal-to Noise Ratio Frequency Response Tuning Range Intermediate Frequenc
ZENITH ELECTRONICS CORPORATION LIMITED WARRANTY (USA) Zenith will repair or replace your product, at Zenith’s option, if it proves to be defective in material or workmanship under normal use during the warranty period listed below from the date of original consumer purchase. This warranty is good only to the original purchaser of the product during the warranty period as long as it is in the United States, excluding US Territories.
