Installation Manual

ManualsBrandsXaptum ManualsElectronicsCommunication Module

2AQPLLBEE5HY1MW Installation Manual

FCC ID of this product is as follows.

FCC ID: 2AQPLLBEE5HY1MW

IC No. of this product is as follows.

IC: 24569-LBEE5HY1MW

Contents

1. Supply Voltage

2. Theory of Operation & Channel List

3. Antenna

1. Supply Voltage

1: VIO does not influence the RF characteristics.

2. Theory of Operation & Channel List

The following table lists the supported channels and operating modes. If the module is installed

in hardware that supports an external dipole antenna, the italicized modes of operation must be

disabled in firmware or software.

Xaptum, Inc.

541 N Fairbanks, Suite 2200 1

Chicago, IL 60611

Parameter

Min.

Typ.

Max.

Unit

Operating Temperature

-30

+85

°C

Supply Voltage

VBAT

3.2

3.3

4.8

VIO

1

1.8V/3.3V

1.62

3.63

Frequency of Operation

Scan

Antenna

Trace

Dipole

2.4

GHz

11b/g/n - HT20

2412-2462MHz

Active

✓

2402-2480MHz

N/A

✓

Summary of content (4 pages)

PAGE 1
2AQPLLBEE5HY1MW Installation Manual FCC ID of this product is as follows. FCC ID: 2AQPLLBEE5HY1MW IC No. of this product is as follows. IC: 24569-LBEE5HY1MW Contents 1. Supply Voltage 2. Theory of Operation & Channel List 3. Antenna 1. Supply Voltage Parameter Min. Typ. Max. Unit Operating Temperature -30 25 +85 °C Supply Voltage VBAT 3.2 3.3 4.8 V VIO1 1.8V/3.3V 1.62 - 3.63 V 1: VIO does not influence the RF characteristics. 2.
PAGE 2
W52 W53 W56 W58 BLE 2402-2480MHz N/A ✓ 11a/n/ac - (V)HT20 5180-5240MHz Active ✓ ✓ 11n/ac - (V)HT40 5190-5230MHz Active ✓ ✓ 11ac - VHT80 5210MHz Active ✓ 11a/n/ac - (V)HT20 5260-5320MHz Passive ✓ 11n/ac - (V)HT40 5270-5310MHz Passive ✓ 11ac - VHT80 5290MHz Passive ✓ 11a/n/ac - (V)HT20 5500-5720MHz Passive ✓ 11n/ac - (V)HT40 5510-5710MHz Passive ✓ 11ac - VHT80 5530-5690MHz Passive ✓ 11a/n/ac - (V)HT20 5745-5825MHz Active ✓ ✓ 11n/ac - (V)HT40 5755-5795MHz Ac
PAGE 3
Antenna Connector 50 ohm U.FL 50 ohm feed line length We test it at 1mm as representative 3.3 Antenna Trace Layout Guide 4. Regulatory Requirements 4.1 Labeling Guidelines The following information must be indicated on the host device of this module or, if it cannot be described on the host device, must be listed in the host product manual.
PAGE 4
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions. 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Contains IC 24659-LBEE5HY1MW This device complies with ISED Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2.
