MODEL WSP-R341 (3inch Mobile Printer) Rev. 1.0 WOOSIM SYSTEMS Inc. (#501, Daerung Technotown 3th) 115, Gasan digital 2-ro, Geumcheon-gu, Seoul, 153-772 Rep. of KOREA Tel : +82-2-2107-3700 Fax : +82-2-2107-3707 URL: http://www.woosim.com All specifications are subjected to change without notice http://www.woosim.
WSP-R341 Rev. 1.0 Copyright WSP-R341 3inch mobile printer operator’s manual. Copyright ⓒ2015 by Woosim Systems Inc. All rights reserved. The information contained in this manual is the property of Woosim Systems Inc. And may not be reproduced in whole or in part without the prior written permission of Woosim Systems Inc. Trademark a registered trademark of Woosim Systems Inc. All other trademark are the properties of their respective companies.
WSP-R341 Rev. 1.0 Introduction The WSP-R341 is suitable designed for use with a growing variety of mobile devices. Bluetooth/USB interfaces make the WSP-R341 the perfect comrade for applications such as point of transaction warehousing, distribution, point of sales, hospitality, gaming and healthcare. The general features of WSP-R341 printer are as follows: Pocket size (104.5 x 126.8 x 45.1mm) Light weight (297.5g) for true mobility. Very silent printing thru direct thermal printing method.
WSP-R341 Rev. 1.0 Operating Precautions Please follow the precautions below to enjoy and maintain the full performance of the printer. Using the Printer ● Be careful not to drop or bump the printer on a hard surface. ● Do not install the printer in direct sunlight or such areas.
WSP-R341 Rev. 1.0 Federal Communications Commission Radio Frequency Interference Statement FCC ID : QDDWSP-R341 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
WSP-R341 Rev. 1.0 CONTENTS 1. Outline ................................................................................................................................... 7 1.1. Model classifications .................................................................................................... 7 1.2 Symbol ............................................................................................................................ 7 1.3. Product Part Number System........................................
WSP-R341 Rev. 1.0 1. Outline 1.1. Model classif ications WSP-R341 ( ) ( ) Model Interface C1 : USB/Bluetooth Power None : DC 8.4V 1.2 Symbol Standby symbol IEC 5009, the standby symbol(line partially within a broken circle), Indicates a sleep mode or low power state. Direct current symbol This symbol is found on many electronic devices that either require or produce direct current. http://www.woosim.
WSP-R341 Rev. 1.0 1.3. Product Par t Number System Model name S40 SC30 W25 Example) 1. Porti-S40 / Interface Spec. Wired Wireless A RS-232C 1 Bluetooth B TTL 2 IrDA 0 None . C USB D RS-485 . E Parallel . Z None UART/Bluetooth Part No. ⇒ S40/A1 2. Porti-SC30 Bluetooth Only Part No. ⇒ SC30/Z1 Note) The above table is the interface format which is supported.
WSP-R341 Rev. 1.0 1.4. Specif ications.
WSP-R341 Rev. 1.0 Item Specification Battery Rechargeable 7.4V DC , 1800mAh (Li-ion) Battery duration 1 hour continuous printing Battery Charger Environment Conditions Limited Warranty of Life Input (100~240V AC 50~60Hz) Output(8.4VDC/0.8A), 4hours full charge time Temperature Humidity Head -10°C ~ 50°C (operating) -10°C ~ 70°C (storage) 30% - 80% (operating) 10% - 90% (storage) 50Km < Table 1 > http://www.woosim.
WSP-R341 Rev. 1.0 2. Setting up the printer 2.1. Printer & Accessories Your printer box should include these items. If any items are damaged or missing, please contact your dealer for assistance. WSP-R341 User’s Manual Battery Pack Thermal roll paper A800-018 Battery charger adaptor ▼ OPTIONAL Belt Clip MSR Communication cable http://www.woosim.
WSP-R341 Rev. 1.0 2.2. Printer Features ▶ Part Name http://www.woosim.
WSP-R341 Rev. 1.0 2.3. Dimensions None MSR MSR http://www.woosim.
WSP-R341 Rev. 1.0 2.4. Replacing the paper roll Note : Be sure to use paper rolls that meet the specifications. Do not use paper rolls that have the paper glued to the core because the printer can not detect the paper end correctly. 1. Make sure that the printer is not receiving data; otherwise, data may be lost. 2. Open the paper cover as the “One-Touch” way by pressing the button in the arrow direction like the picture. 3. Insert the paper roll as shown. 4.
WSP-R341 Rev. 1.0 2.5. Power supply 2.5.1. Internal power supply The following specification is requested for Power supply. Battery Charger : DC 8.4V/0.8A Avoid using power supply which its power capacity of power current is extremely high. 2.5.2. Installing the Batter y Warning : ● Before installing or removing the battery pack, ensure the printer is OFF. ● If the printer is not used for long period of time, remove the battery pack from the printer.
WSP-R341 Rev. 1.0 2.5.3. Recharging the batter y For recharging the battery pack, install the battery pack in the printer. Insert the Battery Charger to the charge connector of the printer. NOTE : ● While charging the printer, turn off the printer power. ● Do not remove the battery during charging. ● The battery is consumable parts and when purchasing, compared to the use hour is gradually decreases.
WSP-R341 Rev. 1.0 2.6. Set operation mode In keeping on pressing the Feed and Power button simultaneously until after the ERROR lamp blinks 5 times, the printer comes out at the circumstance to change the printer mode. (refer to Table 2) POWER button : use for changing OPTION status. (Error Lamp) FEED button : use for changing MODE status. (Power Lamp) *Note No additional mode settings are required to connect Android or iOS devices.
WSP-R341 Rev. 1.0 [Example] The defaults of the printer are : USB / Density Low / Mark No Use / Sensor High / PWDN 5 min slp If a user wants to modify the defaults with Bluetooth / Density High / Mark Use / Sensor Low / PWDN No Use Press FEED & POWER Button during the Error Lamp flickers 5 times. You will see the Power Lamp and the Error Lamp flickers once. Press the POWER Button twice and the Error Lamp flickers 3 times. And then, interface mode has set to Bluetooth mode.
WSP-R341 Rev. 1.0 2.6.1. GAP/HOLE SENSOR SETTING 1. Set Mark as GAP / HOLE on mode setting. 2. If feed button keeps being pressed during self “SENSOR SETTING” appears on LCD window and paper keeps coming out “SENSOR SETTING”. 3. If feed button is not pressed after printing more than 3 pages of label 4. Setting is completed as Green and Red LED flash and “COMPLETE” appears on LCD window. ** Caution : Sensor setting stops if the feed button is not pressed during self test. http://www.woosim.
WSP-R341 Rev. 1.0 2.7. Memor y switch table Mode 2 3 4 Etc. Mode Option 1 USB 1 No use 2 USB(Pro) 2 1min Sleep 3 Bluetooth 3 2min Sleep 4 Bluetooth(Pro) 4 3min Sleep 5 Bluetooth(iAP) 5 4min Sleep 1 Low 6 5min Sleep 2 Medium 7 1min Off 3 High 8 2min Off 1 No use 9 3min Off 2 Use 10 4min Off 3 Gap / Hole V 11 5min Off 4 Back V 1 Low Sensor 2 Medium1 sensitivity 3 Medium2 4 High Communi1 Option cation Port Density Mark V 5 Power Down Etc.
WSP-R341 Rev. 1.0 3. Inter face 3.1. USB (Fig.3.1) The WSP-R341 printer has a USB interface and is connected by means of a 5 pin mini USB socket. In the following table, the signals present on the Mini- USB socket are listed: ① USB Pin No. Name Function 1 VCC +5V 2 DM DATA “-” 3 DP DATA “+” 4 NC. - 5 GND Ground NOTE : ● If you connect the printer interface cable is converted to USB mode. ● When data receiving, when it removes the communication cable, it loses a data. http://www.
WSP-R341 Rev. 1.0 3.2. Bluetooth Category Specification Bluetooth Spec. Bluetooth Ver3.0 / Class2 (10m) Frequency band 2402~2480 MHz Protocol L2CAP, RFCOMM, SDP Profile GAP, SDAP, SPP 3.3. Read a magnetic stripe card ▶ Check the direction of the magnetic stripe and swipe the card. ▶ Cards can be swiped in two ways. ▶ When the card reading is successful, buzzer sound one time. If it fails, buzzer sounds three times. http://www.woosim.
WSP-R341 Rev. 1.0 4. Using the printer 4.1. Control panel (Fig.4.1) Button - FEED Button : Use feed button to feed the paper continuously. - POWER Button : This button is used to power on/off. When of 5 or more seconds presses and power comes to on or off. : In keeping on pressing the Feed and Power button simultaneously until after the ERROR lamp blinks 5 times, the printer comes out at the circumstance to change the printer mode. (Refer to 2.6.
WSP-R341 Rev. 1.0 LAMP - Power : Printer is ON and ready to receive data. (GREEN) - Error : Indicates a fault condition or a printer error. (RED) (details: no paper, paper cover opened. etc.) - Bluetooth : Indicates a Bluetooth connection status. (BLUE) - Battery Power : These lamps(Green) indicated the battery power remaining. (GREEN) The battery gain in quantity and these lamps are on the decrease. If so, you must recharge the battery by using the battery charger. 4.2.
WSP-R341 Rev. 1.0 4.3. Using the Belt clip Following the instruction of the arrow, please put the belt clip in the hole and turn and fix the screw to the right by using a thing like a screw driver. Afterward, you can use it like the picture below http://www.woosim.
WSP-R341 Rev. 1.0 5. Consumable Par ts 5.1. Recommended paper Type : Thermal Paper Paper width : 80mm Paper thickness : 60±5㎛ Outer diameter : Ø40mm or less Recording side : Outside of roll Cautions 1. Do not paste the paper to the core, and the roll paper which has near end mark printing on its near end is recommended. 2. Chemicals or oil may change the color of paper, or printed characters may fade. 3. Change of paper color starts from approx. 70 ℃.
WSP-R341 Rev. 1.0 6. Revision Histor y Date Version Nov. 02. 2015 1.0 Comments Initialize http://www.woosim.
