User's Guide
Boost button
LED Indicator
REMOTE USER GUIDE
WB-RC01
Throttle
Snap latch
Take out the screw
Note :
Battery size:3AAA
First time pairing.
How to control the Wheeebo ?
1. Once you fall down from the Wheeebo, release
the throttle instantly !
2. When waterproof case get damaged, stop to
use the remote !
Keep pressing the throttle to ride the Wheeebo
How to change battery ?
After standby 10 minutes, the remote will change to
sleep mode, press Boost button to wake it up.
1.Turn ON the Wheeebo’s power.
2.Press Boost button to wake up the remote.
3.When the remote’s LED slow flashes is stop,
it means they are paired
Battery level check
1.Press BOOST button to wake up the remote.
2.Press BOOST button twice to check battery voltage:
LED flashes once = battery low ,flashes twice = battery half0,
flashes thrice = battery full
Waterproof case
Using time
Battery size
Weight
*without battery
Standby time
Water-proof
*must in the waterproof case
15 hr
AAA
116 g
17 hr
IPX 7
SPECS
Release the throttletostoptheWheeebo
Keep pressing throttle then press and hold Boost
button to make the speed faster
WARNING
❶
❷
FCC Statement
This device complies with Part 15 of the FCC Rules. Opera�on is subject to the following two condi�ons:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired opera�on.
FCC Cau�on!
Any changes or modifica�ons not expressly approved by the party responsible for compliance could void the user's authority
to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protec�on against harmful interference in a residen�al installa�on.
cause harmful interference to radio communica�ons. However, there is no guarantee that interference will
not occur in a par�cular installa�on.
If this equipment does cause harmful interference to radio or television recep�on, which can be determined by turning the equipment off and on,
The user is encouraged to try to correct the interference by one or more
of the following measures:
—
Reorient or relocate the receiving antenna.
—
Increase the separa�on between the equipment and receiver.
—
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
—
Consult the dealer or an experienced radio/TV technician for help.
“RF Exposure Warning!
This device contains transmitters and receivers which emit Radio Frequency (RF)
energy. The device is designed to comply with the limits for exposure to RF energy set
by the Federal Communications Commission (FCC) of the United States,Industry Canada
(IC) of Canada, and the regulating entities of other countries.”
`
