User Documentation

Weidmüller Interface GmbH Co. KG; Klingenbergstraße 16, 32758 Detmold-Germany
Order No
Version:
AMC 2.5
2434340000
Type
Order No
AEP MC 2.5*
2433820000
AEB 35 SC/1*
1991920000
TS 35/… acc.to DIN EN 60715
Plugable
Order No
ZQV 2,5N/2*
1527540000
ZQV 2,5N/3*
1527570000
ZQV 2,5N/4*
1527590000
ZQV 2,5N/5*
1527620000
ZQV 2,5N/6*
1527630000
ZQV 2,5N/7*
1527640000
ZQV 2,5N/8*
1527670000
ZQV 2,5N/9*
1527680000
ZQV 2,5N/10*
1527690000
- Type
Wemid
CTI
≥
600
V0
-60°C…+55°C (for T5 applications)
-60°C…+70°C (for T4 applications)
* in all colours
Standards:
EN 60079-0:2018 and EN 60079-7:2015 A1:2018
IEC 60079-0: 7th Edition and IEC 60079-7: 5.1th Edition
Modular Terminal Blocks: AMC 2.5
- Ambient temperature range
Cross-connection
Accessories:
end plate
end bracket
Terminal rail
Insulation material:
- Operating temperature range
INSTALLATION INSTRUCTIONS
& CONDITIONS FOR SAFE USE
-60°C…+40°C (for T6 applications) - Ambient temperature range
- Tracking resistance (A) to IEC 60112
- Flammability class to UL 94
-60°C…+110°C (insulating material limit)
Ex eb IIC Gb
II 2 GD
Modular TERMINAL Blocks: A- Series
TÜV 16 ATEX 7909 U
IECEx TUR 16.0036 U
Notified Body No. of Ex - QA: 0344
Label print on package unit: 0344
- Ambient temperature range
Version: AMC 2.5; 11620131 ; Index: 02; Date: 06.2019
