Brochure

CC8370-HV
Anti-Ligature Fisheye Network Camera
3MP • WDR Pro • 3DNR • 180° Panoramic View • IK10 •
IP66 • SNV • Anti-Ligature • Anti-Grip
VIVOTEK’s CC8370-HV is a vandal-proof fisheye network camera offering up to 30
fps at 3-Megapixel resolution. With its unique anti-grip design and inconspicuous
appearance, the CC8370-HV plays a life secure guard role in unique security
environments. Without ligature edges, it will effectively eliminate self-harm and
suicide happen, ideal for detention house, holding cells, psychiatric ward, mental
hospital, and correctional institution. Featuring 180° horizontal panoramic views
with adjustable 25° tilt angle, the camera allows users amazing flexibility of
viewing angles and options. The camera’s weather-proof compact size also makes
it an ideal choice for indoor and outdoor scenario such as boutique, convenience
store, bank, school, parking lot and street.
The CC8370-HV can view at a wide angle of 180 degrees, providing complete video
security with no dead angles. Featuring WDR Pro, the camera captures both the
dark and bright areas of an image and combines the differences to create a highly
realistic representation of the original scene. Further, with added SNV technology,
high-quality full-color surveillance video becomes possible even under low-light
conditions. These combined features enable the camera to provide video quality
remarkably close to the capabilities of the human eye. When installing the unit, the
unique mounting design facilitates easy installation on a wall or desktop in order
to capture faces at eye level. Further increasing the level of surveillance, a built-in
microphone which records sound within a 5 meter radius.
The CC8370-HV also supports the industry-standard H.264 compression
technology, drastically reducing file sizes and conserving valuable network
bandwidth. Together with the ST7501 multi-lingual 32-channel recording software,
users can simply and quickly set up an easy-to-use IP surveillance system.
• 3-Megapixel CMOS Sensor
• 30fps @ 2048x1536
• Anti-Ligature Design
• Weather-proof IP66-rated and Vandal-proof IK10-rated Housing
• 180° Horizontal Panoramic View
• ±25° Tilt Lens
• WDR Pro (100dB) to Provide Extreme Visibility in High Light Contrast
Scenes
• Video Rotation
• Built-in Microphone
• SNV (Supreme Night Visibility)
• 3D Noise Reduction for Low-light Conditions
• Real-time H.264 and MJPEG Compression (Dual Codec)
• Built-in IEEE 802.3af Compliant PoE
• Built-in MicroSD/SDHC/SDXC card slot
Key Features
Holding Cell
Psychiatric Ward
Prison
Retail Store
25°
Anti-Ligature
25°
The World's First Adjustable Tilt Angle Fisheye Network Camera
