OPERATING INSTRUCTIONS RD-8601 Audio/Video Receiver
Introduction This symbol is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. CAUTION WARNING : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
ENGLISH SAFETY INSTRUCTION 1. Read Instructions - All the safety and operating instructions should be read before the product is operated. 2. Retain instructions - The safety and operating instructions should be retained for future reference. 3. Heed Warnings - All warnings on the product and in the operating instructions should be adhered to. 4. Follow Instructions - All operating and use instructions should be followed. 5. Cleaning - Unplug this product from the wall outlet before cleaning.
CONTENTS Introduction | 2 ENGLISH • READ THIS BEFORE OPERATING YOUR UNIT • SAFETY INSTRUCTION | 3 System Connections | 5 Front Panel Controls | 11 Universal Remote Controls | 13 • OPERATING COMPONENTS WITH REMOTE CONTROL • REMOTE CONTROL OPERATION RANGE | 15 • LOADING BATTERIES | 15 • USING FUNCTIONS OF REMOTE CONTROL | 16 | 15 Speaker Setup | 19 • SETTING THE SPEAKER SETUP MANUALLY | 20 • SETTING THE SPEAKER SETUP AUTOMATICALLY (AUTO SPEAKER SETUP) Operations • LISTENING TO A PROGRAM SOURCE | 25 • SUR
• Do not plug the AC input cord into the wall AC outlet until all connections are completed. • Be sure to observe the color coding when connecting audio, video and speaker cords. • Make connections firmly and correctly. If not, it can cause loss of sound, noise or damage to the receiver.
2. CONNECTING VIDEO COMPONENTS VIDEO 2 DVD player, etc. VIDEO 1 Video deck, DVD recorder, etc.
3. CONNECTING AUDIO COMPONENTS ENGLISH • The AUX jacks may be connected to an additional audio component such as a CD player, a tape deck, etc. TAPE Tape deck, MD recorder, etc. L AUDIO R OUT L R CD AUDIO IN AUX CD player AUDIO L OUT R L R PLAY CD other audio component AUDIO OUT REC TAPE AUX 4. CONNECTING EXTERNAL INs EXTERNAL IN SUB WOOFER CENTER • Use these jacks to connect the corresponding outputs of a DVD player or external decoder, etc.
6. CONNECTING SYSTEM CONTROL • Connect this jack to the DIGI LINK jack of the external Sherwood component that uses the DIGI LINK II or III remote control system. Sherwood component with DIGI LINK II or III System control cord Tape deck DIGI-LINK DVD player 7. SUBWOOFER PREOUT connection • To emphasize the deep bass sounds, connect a powered subwoofer. PRE OUT SUB WOOFER Powered subwoofer 8.
Speaker placement ENGLISH Ideal speaker placement varies depending on the size of your room and the wall coverings, etc. The typical example of speaker placement and recommendations are as follows : TV or SCREEN 1 SUBWOOFER ■Front left and right speakers and center speaker FRONT (LEFT) • Place the front speakers with their front surfaces as flush with TV or monitor screen as possible.
9. CONNECTING MICROPHONE Note: • Because the microphone for Auto Speaker Setup is designed for use with this receiver, do not use a microphone other than the one supplied with this receiver. 10. SWITCHED AC OUTLETs • Theses outlets are switched on(power-on mode) and off(standby mode) according to power control as follows(Maximum total capacity is 100 W, 1 A). Standby mode - Switched AC outlet off Power-on mode - Switched AC outlet on 11. AC INPUT CORD • Plug this cord into a wall AC outlet.
Front Panel Controls ENGLISH 23 24 26 25 21 20 AUDIO/VIDEO RECEIVER RD-8601 MASTER VOLUME POWER REMOTE SENSOR 1 ON/ 2 22 OFF INPUT SELECTOR STANDBY AUDIO VIDEO SURROUND MODE EXTERNAL IN AUTO DSP MODE STEREO PARAMETER DIGITAL INPUTS ON/STANDBY 27 16 3 VIDEO 3 PHONES CHANNEL SELECTOR SPEAKER ADJUST TONE MODE SPEAKER SETUP DYNAMIC RANGE CINEMA EQ MEMO/ENTER TUNING/PRESET T/P MODE FM MODE BAND ON/OFF VIDEO 4 5 6 7 8 9 10 11 1. POWER switch 2.
■ VIDEO 3 INPUT JACKS ENGLISH VIDEO 3 L - AUDIO - R VIDEO VIDEO 3 VIDEO L - AUDIO - R When not using the VIDEO 3 INPUT jacks, cover these jacks with the supplied cap. L VIDEO OUT VIDEO 3 R AUDIO OUT • The VIDEO 3 jacks may be also connected to an additional video component such as a camcorder, LD player, video game player, etc. Camcorder, video game player, etc.
ENGLISH Universal Remote Controls This universal remote control can operate not only this receiver but also most popular brands of audio and video components such as CD players, cassette decks, TVs, cable boxes, VCRs, DVD players, satellite receivers, etc. • To operate 7 components other than this receiver, you should enter the setup code for each component. (For details, refer to “USING FUNCTIONS OF REMOTE CONTROL” on page 16.
FUNCTION TABLE of the NUMBERED BUTTONS Button symbol CD AUX TV VCR (for CD player) (for tape deck) (for TV) (for VCR) DVD CBL SAT (for DVD player) (for satellite receiver) (for cable box) 1 POWER ON POWER ON POWER ON POWER ON POWER ON POWER ON POWER ON POWER ON 2 STANDBY STANDBY (POWER OFF) STANDBY (POWER OFF) STANDBY (POWER OFF) STANDBY (POWER OFF) STANDBY (POWER OFF) STANDBY (POWER OFF) STANDBY (POWER OFF) ENGLISH Device to be controlled CH.
ENGLISH OPERATING COMPONENTS WITH REMOTE CONTROL 1 2 REMOTE CONTROL OPERATION RANGE Enter the setup code for each component other than this receiver you wish to control. For details, refer to “Entering a setup code” on page 16. • Use the remote control unit within a range of about 7 meters (23 feet) and angles of up to 30 degrees aiming at the remote sensor. Turn on the component you want to operate.
• This remote control can control up to 8 different components. • Before operating audio and video components other than this receiver with using this remote control, the setup code for each component should be entered. • For system remote control operation, “000” was stored previously in the memory of the device button “CD” for Sherwood CD player, “DVD” for Sherwood DVD player and “AUX” for Sherwood tape deck respectively as its factory setup code.
T.TONE OSD MENU DVD VCR SAT CBL SETUP ENTER CH.SEL SLEEP DIMMER DISPLAY RETURN T/V CH/LEVEL TUNE MUTE TUNE T.TONE PRESET P.SCAN OSD PRESET MENU SETUP ENTER ENTER AUTO DSP STEREO SPK SET ADJUST PARAMATER SLEEP DIMMER DISPLAY RETURN TUNE TUNE PRESET 1 2 3 4 5 6 7 8 9 0 +10 0 MACRO M1 M2 M3 1 0 REMOTE CONTROL RNC-50A P.
POWER ON STANDBY CD CBL DVD VCR AUX TV SAT CBL CH.SEL T/V CH/LEVEL MUTE T.TONE OSD MENU POWER ON RETURN AUX TV SAT CBL DVD VCR DIMMER DISPLAY TUNE STANDBY CD SETUP ENTER SLEEP OSD CH.SEL TUNE T/V PRESET P.SCAN CH/LEVEL PRESET MUTE T.TONE AUTO DSP STEREO SPK SET ADJUST PARAMATER OSD MENU SETUP ENTER SLEEP 2 1 3 4 6 7 8 0 +10 DIMMER DISPLAY TUNE PRESET 9 MACRO M2 SETUP RETURN TUNE 5 M1 P.
ENGLISH Speaker Setup • After you have installed this receiver and connected all the components, you should adjust the speaker settings for the optimum sound acoustics according to your environment and speaker layout. • Even when you change speakers, speaker positions, or the layout of your listening environment, you should adjust the speaker settings, too.
SETTING THE SPEAKER SETUP MANUALLY ENGLISH Note: When the SPEAKER button is set to off or the EXTERNAL IN is selected as an input source, the speaker setup procedure cannot be performed. Before setting the speaker setup • Press the POWER switch to enter the standby mode and then turn the power on. POWER POWER ON POWER ON AUD STANDBY CD VCR AUX DVD TV SAT SA CBL POWER ON STANDBY DEVICE SELECT CD AUX TV SAT CBL CH.SEL STANDBY VCR T/V CH/LEVEL DVD VOLUME MUTE T.TONE .TONE OSD CH.
Continued ENGLISH • When selecting the distance of front left speaker, • You can adjust the distance within the range of 1 ~ 30 feet in 1 foot intervals. 1 (ft) ~ 30 (ft) “FRONT L 10 (ft)” • When selecting the distance of front right speaker, • You can adjust the distance within the range of 1 ~ 30 feet in 1 foot intervals. 1 (ft) ~ 30 (ft) “FRONT R 10 (ft)” • You can adjust the distance within the range of 1 ~ 30 feet in 1 foot intervals.
• Auto Speaker Setup lets you avoid troublesome listening-based speaker setup and achieve good surround sound. You should connect the microphone to the SETUP MIC jack so that this receiver can analyze the information from a series of test tones emitted from speakers and can adjust the size, distance and sound level of each speaker automatically.
ENGLISH 4 Specify the setting condition. When specifying the number of speakers installed. • Each time this button is pressed, the speaker layout changes as follows: POWER ON AUD SPEAKER SETUP STANDBY CD VCR DVD AUX TV SAT SA CBL ALL : All speakers DEVICE SELECT CH.SEL T/V CH/LEVEL VOLUME MUTE T.TONE .TONE OSD MENU or 3/2 : 2 front, center and 2 surround speakers SETUP ENTER SLEEP DIMMER DISPLAY DISPLA RETURN TUNE TUNE PRESET P.
POWER ON AUD SPEAKER SETUP POWER ON STANDBY CD VCR 7 Confirm the results. AUX DVD AUD TV SAT SA AUX DVD T/V CH/LEVEL VOLUME MUTE T.TONE .TONE OSD MENU SETUP SETUP ENTER ENTER DISPLAY DISPLA RETURN TUNE TUNE P.SCAN ADJUST TUNER CD AUX 2 1 3 VIDEO 1 SLEEP DIMMER DISPLAY DISPLA RETURN TUNE STEREO AUTO PARAMA ARAMATER SPK SET TAPE TUNER 4 1 6 7 9 0 +10 P.
Operations ENGLISH • Note : Before operating this receiver with the supplied remote control, refer to “Universal Remote Controls” on page 13 for details about operation. LISTENING TO A PROGRAM SOURCE Before operation • Enter the standby mode. 3 POWER Select the desired input source. POWER ON POWER ON STANDBY CD DVD VCR AUX TV SAT CBL CH.SEL T/V CH/LEVEL • The STANDBY indicator lights up.
7 To compensate for edgy or shrill movie sound tracks. CINEMA EQ Select the digital or analog input connected as desired. 4 ENGLISH When CD, VIDEO 1~3 is selected as an input source DIGITAL INPUTS • Then “C-EQ OFF” is scrolled. • Press it again to work, the “C-EQ ON” is scrolled. • When 96 kHz PCM(2 CH stereo) signals are input or the SPEAKER button is set to off, the cinema EQ function does not work.
ENGLISH Adjusting the tone(bass and treble) 11 Enter the tone mode. 10 At the desired tone mode, adjust the tone as desired. ADJUST TONE MODE • At “TONE ON” mode, you can select “TONE OFF” mode and vice versa. TONE ON : When adjusting the tone for your taste. (“DIRECT” indicator goes off.) TONE OFF : When listening to a program source without the tone effect. (“DIRECT” indicator lights up.
SURROUND SOUND Surround modes • DTS Neo : 6 Cinema This mode is optimum for playing movies. Decoding is performed with emphasis on separation performance to achieve the same atmosphere with 2-channel sources as with 6.1-channel sources. ■DTS Digital Surround DTS Digital Surround(also called simply DTS) is a multichannel digital signal format which can handle higher data rates. Discs bearing the “ ” include the recording of up to 5.
ENGLISH ■Dolby Pro Logic IIx surround ■Dolby Headphone Dolby Pro Logic IIx decodes all stereo (2 channel ) and 5.1 channel sources and extends to 7.1channel surround playback. It delivers the most natural, full range and immersing 7.1 channel listening experience. Dolby Pro Logic IIx surround includes two modes as follows : The Dolby Headphone function simulates 5.1 channel surround sound, which allows you to enjoy 5.1 channel surround sound through 2 channel headphones, just like listening from 5.
• Surround sound effect will not work properly if the signal passes through a graphic equalizer. Please refer to your equalizer operating instructions for guidance on switching off (or defeating) the equalizer. Note: • Before surround playback, first perform the SPEAKER SETUP procedure, etc. for optimum performance. (For details, refer to “Speaker Setup” on page 19.) 1 Depending on the input digital signal format, select the desired decoding mode.
CH.SEL T/V CH/LEVEL MUTE T.TONE OSD MENU SETUP ENTER SLEEP DIMMER DISPLAY RETURN TUNE TUNE PRESET P.SCAN Continued PRESET DSP AUTO STEREO ADJUST SPK SET 1 2 5 9 DSP PARAMATER 3 4 6 7 8 0 +10 MACRO M1 M2 M3 REMOTE CONTROL RNC-50A To cancel the surround mode for stereo operation POWER ON AUD STERO • Depending on the signal format which is being input, either the stereo mode or the 2CH downmix mode is selected.
DSP AUTO STEREO ADJUST SPK SET SPK SET PARAMATER 1 2 3 4 5 6 7 8 0 +10 9 MACRO M1 M2 M3 REMOTE CONTROL RNC-50A POWER ON ADJUST AUD STANDBY CD VCR 3 Repeat the above steps ① and ② to adjust other parameters. ENGLISH 2 At the desired parameter, adjust it as desired. AUX DVD TV SAT SA CBL DEVICE SELECT CH.SEL T/V CH/LEVEL VOLUME MUTE T.TONE .TONE or OSD MENU SETUP ENTER SLEEP DIMMER DISPLAY DISPLA RETURN TUNE TUNE PRESET ADJUST P.
TUNE TUNE PRESET P.SCAN AUTO DSP SPK SET ADJUST ADJUST PRESET STEREO PARAMATER 1 2 3 4 5 6 7 8 0 +10 9 POWER ON STANDBY CD VCR DVD AUX TV SAT CBL MACRO M1 M2 MUTE CH.SEL M3 T/V CH/LEVEL MUTE REMOTE CONTROL RNC-50A T.TONE OSD MENU SETUP ENTER DIMMER SLEEP DISPLAY RETURN TUNE TUNE PRESET P.SCAN POWER ON VCR STANDBY AUX TV SAT CBL 9 T/V 2 T.TONE OSD MENU SETUP ENTER DIMMER SLEEP DISPLAY RETURN TUNE TUNE PRESET P.
• You can memorize the adjusted channel levels into preset memory(“REF. 1”, “REF. 2”) and recall the memorized whenever you want. 1 After performing the steps ①~③ in “Adjusting the current channel level” procedure on page 33, press the (MEMORY/) ENTER button. POWER ON POWER ON AUD STANDBY STANDBY CD CD AUX TV DVD SAT SA CBL VCR VCR DVD AUX TV SAT CBL DEVICE SELECT MEMO/ENTER CH.SEL T/V CH.SEL T/V CH/LEVEL CH/LEVEL MUTE VOLUME MUTE T.TONE T.TONE .
POWER ON STANDBY CD VCR DVD AUX TV SAT CBL CH.SEL T/V CH/LEVEL MUTE T.TONE OSD MENU SETUP LISTENING TO RADIO BROADCASTS ENTER SLEEP DIMMER DISPLAY RETURN TUNE 1 TUNE PRESET P.SCAN PRESET AUTO DSP STEREO SPK SET ADJUST PARAMATER 2 1 5 9 3 4 6 7 8 0 +10 2 3 4 6 7 8 MACRO M1 M2 M3 ENGLISH REMOTE CONTROL RNC-50A Auto tuning 1 2 Select the tuner. Select the desired band.
POWER ON STANDBY CD VCR DVD AUX TV SAT CBL CH.SEL T/V POWER ON CH/LEVEL STANDBY MUTE CD T.TONE OSD MENU VCR DVD AUX TV SAT CBL SETUP ENTER CH.SEL T/V SLEEP DIMMER CH/LEVEL DISPLAY MUTE RETURN TUNE TUNE PRESET P.SCAN AUTO PRESET DSP ADJUST SPK SET T.TONE TUNE TUNE OSD MENU SETUP ENTER SLEEP DIMMER DISPLAY RETURN STEREO TUNE PARAMATER TUNE PRESET 1 2 3 4 5 6 7 8 9 0 +10 DSP ADJUST MACRO M1 M2 P.
MENU SETUP ENTER DIMMER SLEEP DISPLAY RETURN TUNE 1 TUNE PRESET P.SCAN PRESET AUTO DSP STEREO SPK SET ADJUST PARAMATER 2 1 3 4 6 7 8 0 +10 POWER ON 5 9 STANDBY CD VCR AUX TV SAT CBL DVD 2 3 4 6 7 8 MACRO M1 M2 M3 CH.SEL T/V CH/LEVEL MUTE REMOTE CONTROL RNC-50A T.TONE OSD MENU SETUP ENTER RECORDING SLEEP DIMMER DISPLAY RETURN TUNE TUNE PRESET P.
POWER ON STANDBY CD VCR DVD AUX TV SAT CBL CH.SEL T/V CH/LEVEL MUTE OSD SETUP ENTER 3 SLEEP DIMMER DISPLAY RETURN TUNE TUNE PRESET P.SCAN PRESET DSP AUTO ADJUST SPK SET 1 2 3 6 7 4 STEREO PARAMATER 1 2 3 4 5 6 7 8 9 0 +10 8 Start play on the VIDEO 2 and the CD respectively.
AUTO POWER ON VCR AUX TV SAT CBL STEREO T/V MUTE ADJUST SPK SET MUTE CH.SEL CH/LEVEL DSP STANDBY CD DVD PARAMATER 1 2 3 4 5 6 7 8 0 +10 9 MACRO T.TONE OSD M1 MENU M2 M3 SETUP REMOTE CONTROL RNC-50A ENTER DIMMER SLEEP DISPLAY RETURN TUNE TUNE PRESET P.
This unit incorporates an OSD(On-screen display) function to provide information about basic operation of this unit and to simplify the setup procedures. The OSD function uses a monitor TV connected to this unit as a display and has two kinds of display modes such as current status display and menu screen. ■Notes: • Any on-screen display shown on the monitor TV will not be recorded.
DISPLAY ENTER SETUP RETURN TUNE TUNE DIMMER SLEEP PRESET P.SCAN DISPLAY PRESET RETURN TUNE TUNE PRESET P.SCAN PRESET AUTO DSP SPK SET ADJUST STEREO PARAMATER DSP AUTO STEREO 2 1 3 ADJUST SPK SET 5 7 8 3 9 4 0 5 4 PARAMATER 6 2 1 +10 6 7 8 0 MACRO+10 9 M1 M2 M3 MACRO REMOTE CONTROL RNC-55A M2 M3 M1 REMOTE CONTROL RNC-50A 2 Select the desired menu using the CURSOR UP(▲)/DOWN(▼) buttons.
• After you have installed this receiver and connected all the components, you should adjust the speaker settings for the optimum sound acoustics according to your environment and speaker layout. • Even when you change speakers, speaker positions, or the layout of your listening environment, you should adjust the speaker settings, too.
ENGLISH 3 Press the ENTER button to start the auto speaker setup procedure. Example) When analyzing the test tones POWER ON POWER ON AUD AUX TV SAT SA CBL A U T O S E T UP STANDBY CD STANDBY CD DVD VCR VCR AUX TV SAT CBL DVD DEVICE SELECT T/V CH.SEL CH/LEVEL T/V MUTE VOLUME MUTE T.TONE T.TONE .TONE FL OSD OSD MENU MENU SETUP ENTER SLEEP DIMMER DISPLAY DISPLA RETURN TUNE SETUP ENTER PRESET P.
CD VCR AUX TV SAT CBL DVD OSD CH.SEL T/V CH/LEVEL MUTE T.TONE OSD MENU PTY SELECT SETUP RDS ENTER SLEEP SEARCH MODE DIMMER DISPLAY TUNE P.SCAN PRESET DSP STEREO ADJUST PARAMATER 2 1 5 9 POWER ON SETUP RETURN TUNE PRESET AUTO SPK SET 3 4 6 7 8 0 +10 STANDBY MACRO VCR CD AUX TV DVD SAT CBL M1 M2 M3 REMOTE CONTROL RNC-55A OSD CH.SEL T/V CH/LEVEL MUTE Press the CURSOR UP(▲)/DOWN(▼) buttons to select the desired item. T.
SELECTING THE FUNCTION ENGLISH F UNC T I ON SE L E C T To select a digital input To select a video input source To adjust the tone as desired. D I G I T A L I NP U T V I DEO S E L E C T T ONE CON T ROL : MOV E O S D : B A CK EN T ER : SEL . When selecting the DIGITAL INPUT POWER ON AUX DVD SAT CH.SEL T/V CH/LEVEL Note: When TUNER, TAPE, AUX or EXTERNAL IN is selected as an input source, the DIGITAL INPUT cannot be selected. STANDBY CD VCR TV CBL MUTE T.
POWER ON STANDBY CD VCR DVD AUX TV SAT CBL CH.SEL T/V CH/LEVEL MUTE T.TONE OSD MENU SETUP ENTER ENTER SLEEP DIMMER When selecting the VIDEO SELECT DISPLAY RETURN TUNE TUNE PRESET P.SCAN AUTO PRESET DSP STEREO ADJUST SPK SET PARAMATER 1 2 3 4 5 6 7 8 9 0 +10 • Only when one of TUNER, CD, TAPE, AUX and EXTERNAL IN is selected, you can select a video input source on the VIDEO SELECT menu and enjoy the audio and video signals separately.
ADJUST SPK SET PARAMATER MACRO M1 M2 M3 1 2 3 4 5 6 7 8 9 0 +10 REMOTE CONTROL RNC-50A MACRO M1 M2 M3 REMOTE CONTROL RNC-55A POWER ON STANDBY CD VCR AUX TV SAT CBL DVD CH.SEL T/V CH/LEVEL MUTE T.TONE OSD POWER ON MENU STANDBY SETUP CD AUX TV SAT CBL ENTER Set the selected mode as desired. SLEEP DIMMER DISPLAY RETURN TUNE 3 VCR DVD TUNE PRESET P.SCAN CH.SEL T/V PRESET CH/LEVEL MUTE T.
SETTING THE CH LEVEL SETUP : MOV E O S D : B A CK TR I M --------- CH L E V E L --------- SB - - - - - - SL - - - - - - SW - - - - - - DD L - - - - DT S L - - - - - 0 0 0 0 : CHANGE EN T E R : MEMO : MOV E O S D : B A CK TR I M ------------------- 0 0 0 0 0 : C H ANGE EN T E R : MEMO Preset memory mode ■Notes : • Depending on the speaker settings and surround mode, etc., some channels cannot be selected.
AUTO DSP STEREO ADJUST SPK SET PARAMATER 1 2 3 4 5 6 7 8 0 +10 9 MACRO M1 M2 M3 REMOTE CONTROL RNC-50A POWER ON STANDBY CD VCR AUX TV SAT CBL DVD CH.SEL Memorizing the adjusted channel levels T/V CH/LEVEL MUTE T.TONE OSD MENU SETUP ENTER SLEEP DIMMER DISPLAY RETURN • You can memorize the adjusted channel levels into preset memory(“REF. 1”, “REF. 2”) and recall the memorized whenever you want. TUNE TUNE PRESET P.
If a fault occurs, run through the table below before taking your receiver for repair. If the fault persists, attempt to solve it by switching the receiver off and on again. If this fails to resolve the situation, consult your dealer. Under no circumstances should you attempt to repair the receiver yourself. This could void the warranty. PROBLEM POSSIBLE CAUSE REMEDY No power • The AC input cord is disconnected. • Poor connection at AC wall outlet or the outlet is inactive. • Connect the cord securely.
ENGLISH Specifications AMPLIFIER SECTION ×100 W • Power output, stereo mode, 6 Ω, THD 0.2 %, 40 Hz~20 kHz | 2× • Total harmonic distortion, 6 Ω, 95 W, 1 kHz | 0.09% • Intermodulation distortion 60 Hz : 7 kHz= 4 : 1 SMPTE, 6 Ω, 95 W | 0.1% • Input sensitivity/impedance Line (CD, TAPE, VIDEO) | 230 mV/47kΩ • Signal to noise ratio, IHF “A” weighted Line (CD, TAPE, VIDEO) | 90 dB • Frequency response Line (CD, TAPE, VIDEO), 20 Hz~50 kHz | +0, -3 dB • Output level TAPE REC, 2.
Setup Code Table AOC Admiral Aiko Akai Alaron Ambassador America Action Ampro Anam Audiovox Baysonic Belcor Bell & Howell Bradford Brockwood Broksonic CXC Candle Carnivale Carver Celebrity Cineral Citizen Concerto Contec Craig Crosley Crown Curtis Mathes Daewoo Daytron Denon Dumont Dwin Electroband Emerson Envision Fisher Fujitsu Funai Futuretech GE Gibralter 005 041 014 005 026 024 027 043 027 030 027 003 019 027 003 028 027 005 005 010 050 030 012 011 027 027 010 027 007 012 022 030 003 016 002 044 050
ENGLISH Pilot Pioneer Portland Prism Proscan Proton Pulsar Quasar RCA Radio Shack Realistic Runco SSS Sampo Samsung Samsux Sansei Sansui Sanyo Scimitsu Scotch Scott Sears Semivox Semp Sharp Sherwood Shogun Signature Sony Soundesign Squareview Starlite Supreme Sylvania Symphonic TMK Tandy Technics Technoi Ace Techwood Teknika Telefunken Toshiba Totevision Vector Research Victor Vidikron 005 022 003 008 007 025 002 008 007 037 007 003 019 011 002 027 005 012 006 030 031 019 003 025 028 007 011 027 020 041 0
Minolta Mitsubishi Motorola Multitech NEC Nikko Noblex Olympus Opimus Orion Panasonic Penny Pentax Philco Philips Pilot Pioneer Profitronic Proscan Protec Pulsar Quarter Quartz Quasar RCA Radio Shack Radix Randex 011 000 008 014 026 005 015 014 004 005 000 015 004 023 023 023 025 004 023 004 005 004 004 000 008 027 004 000 017 005 023 004 005 031 020 004 004 008 004 004 005 014 023 013 015 007 011 011 004 013 000 005 005 Realistic 008 026 Runco STS Samsung Sanky Sansui Sanyo Scott Sears 026 025 026 005
ENGLISH Magnin Memorex Mitsubishi Orion Panasonic Penney Quasar RCA Sansui Sanyo Sear Sharp Sony Symphonic Zenith 023 005 028 (TV use 025) 027 (TV use 041) 001 004 (TV use 008) 028 (TV use 042) 004 (TV use 008) 023 028 (TV use 042) 004 (TV use 008) 028 (TV use 042) 013 (TV use 012) 004 (TV use 008) 027 (TV use 041) 000 023 000 005 027 (TV use 041) 002 (TV use 000) 000 000 CBL ABC Allegro Archer Bell&Howell Century Citizen Comtronics Contec Easten Emerson Everquest Focus Garrard Gemini General Instrument
010 010 015 014 007 000 010 018 007 153 015 000 022 014 AUX-LD 026 Denon Mitsubishi NAD Pioneer Sony 008 008 001 009 009 016 009 011 007 009 016 006 006 006 017 006 016 003 018 014 004 018 010 006 013 AUX-TAPE 024 Aiwa Carver Harman/Kardon JVC Kenwood Megavox Marantz Onkyo Opimus Panasonic Pioneer Sansui Sony Technics Victor Wards Yamaha 015 018 015 005 005 015 000 005 004 004 016 022 008 004 004 012 002 038 002 004 021 038 024 002 010 034 004 024 025 020 020 011 014 026 009 AUX-AMP 00
ENGLISH AUX-HOME AUTOMATION GE Lutron One For All Radio Shack Security System Universal X10 X10 Kenwood Krell LXI Linn MCS MTC Megavox Marantz Mission NSM Nikko Onkyo Opimus 043 044 042 043 042 042 042 AUX-DBS Awia Fisher Harman/Kardon JBL JVC Jerrold RCA Scientific Artlanta Sony Starcom 045 005 046 046 047 031 006 032 045 031 059 Panasonic Parasound Philips Pioneer Proton QED Quasar RCA Realistic Rotel SAE Sansui Sanyo Scott Sears Sharp Sherwood 029 AUX-ACCESSARY Archer GC Electronics Jebsee Rabbi
RD-8601 Audio/Video Receiver 5707-21128-013-0
