Introduction

ThankyouforpurchasingtheUbiquitiNetworks

™

airFiber

™

24GHz

Point‐to‐PointRadio,modelAF5U.ThisQuickStartGuideisdesignedtoguideyouthroughtheinstallationoftheairFiberAF5U,showyou

howtoaccesstheairFiberConfigurationInterface,andexplainhowtosetupanairFiberlink.

PackageContents



airFiberAF5U PoleMount

Bracket

PoleClamps

(Qty.2)

CableTies

(Qty.2)



 

airFiberAF5U

QuickStartGuide

PoEAdapter

(50V,1.2AGigE)

PowerCord



HardwareOverview

Side



Back



Interfaces



Interface Description

RESET

Toresettofactorydefaults,pressandholdtheRESET

buttonformorethanfivesecondswhiletheunitis

alreadypoweredon.

LEDDisplay

Digitaldisplayusedforpower,status,andmode

information.

DATA 10/100/1000Mbpsporthandlesallusertraffic.

AUX Portforaudiotoneaiming.

Management

10/100Mbps,securedportforconfiguration.By

default,thisistheonlyportthatcanmonitor,configure,

and/orupdatefirmware.



Summary of content (13 pages)

PAGE 1
Introduction Thank you for purchasing the Ubiquiti Networks™ airFiber™ 24 GHz Point‐to‐Point Radio, model AF5U. This Quick Start Guide is designed to guide you through the installation of the airFiber AF5U, show you how to access the airFiber Configuration Interface, and explain how to set up an airFiber link. Package Contents airFiber AF5U Pole Mount Bracket airFiber AF5U Quick Start Guide PoE Adapter (50V, 1.2A GigE) Pole Clamps (Qty. 2) Cable Ties (Qty.
PAGE 2
LEDs DATA Speed Link/Act Management Speed Link/Act Status LEDs GPS Master Link Status Off 10/100 Mbps On 1000 Mbps Off No Ethernet Link On Ethernet Link Established Random Flashing Ethernet Activity Off 10Mbps On 100 Mbps Off No Ethernet Link On Ethernet Link Established Random Flashing Ethernet Activity Off No GPS Synchronization On Operational (Strong Signal) Normal Flash* Operational (Weak Signal) Off Slave Mode On Master Mode Off RF Off Short Flash Syncing No
PAGE 3
(unlabeled) Operational Off No Overload Condition On LEDs Modulation Overload On 8X 6X 4X to 0.25X Overload Condition Reserved On 8X Modulation On 4x Modulation On 6X Modulation Normal Flash 2X Modulation Off 1x and 0.25X Modulation Installation Requirements Clear line of sight between airFiber radios Clear view of the sky for proper GPS operation Mounting location with < 0.
PAGE 4
Installation Overview We recommend that you configure your paired airFiber radios before mounting. Below is an overview of the installation with specific details on the following pages: Connect Power over Ethernet to the DATA port, and connect an Ethernet cable between your computer and the MANAGEMENTport. Configure the device settings in the airFiber Configuration Interface. Once configuration is complete, disconnect the cables to move the airFiber radios. Reconnect at the site.
PAGE 5
Connecting Power over Ethernet Push the button in the Port Cover and slide the Port Cover down to access the RJ45 connectors. Connect an Ethernet cable to the DATA port. Connect the other end of the Ethernet cable from the DATA port to the Ethernet port labeled POE on the PoE Adapter. Connect the Power Cord to the power port on the PoE Adapter. Connect the other end of the Power Cord to a power source.
PAGE 6
Configure the Ethernet adapter on your computer with a static IP address on the 192.168.1.x subnet (for example, 192.168.1.100). Launch your web browser. Type http://192.168.1.20 in the address field and press enter (PC) or return (Mac). The login screen will appear. Enter ubnt in the Username and Password fields. Select your Country and Language. You must agree to the Terms of Use to use the product. Click Login. Note: U.S. product versions are locked to the U.S.
PAGE 7
Configure the Wireless Security: Select the AES Key Type, HEX or ASCII. For the Key field: HEX Enter 16 bytes (eight, 16‐bit HEX values: 0‐9, A‐F, or a‐f). You can omit zeroes and use colons, similar to the IPv6 format. Note: The airFiber Configuration Interface supports IPv6 formats excluding dotted quad and "::" (double colon) notation. ASCII Enter a combination of alphanumeric characters (0‐9, A‐Z, or a‐z). Click Change and then click Apply.
PAGE 8
Connecting Ethernet Turn the Cover Lock to the Unlocked icon. Slide the Port Cover down to remove it. Connect a TOUGHCable or other outdoor, shielded CAT5e/6 cable to the DATA port. Create a strain relief for the Ethernet cable by feeding a Cable Tie through the tie slot alongside the cable. Then wrap the Cable Tie around the cable and tighten. Connect the other end of the Ethernet cable from the DATA port to the Ethernet port labeled POE on the PoE Adapter.
PAGE 9
For the Master and Slave, ensure the Azimuth (AZ) and Elevation (EL) Adjustment Bolts are in the middle of their adjustment ranges. Master Aim the Master at the Slave. If necessary, adjust the Master's position on the pole: Loosen the Hex Nuts. Adjust the Pole Mount Bracket and Pole Clamps. Tighten the Hex Nuts. Slave Aim the Slave at the Master to achieve the strongest received signal level on the Slave's numeric LED Display, which is located next to the MANAGEMENT port.
PAGE 10
Installer Compliance Responsibility Devices must be professionally installed and it is the professional installer's responsibility to make sure the device is operated within local country regulatory requirements. The Frequencies and Output Power fields are provided to the professional installer to assist in meeting regulatory requirements. Specifications Dimensions Weight Operating Frequency Max EIRP Max Power Consumption airFiber AF5U 938.4 x 468.4 x 281.4 mm (36.95 x 18.44 x 11.
PAGE 11
Electrical Safety Information Compliance is required with respect to voltage, frequency, and current requirements indicated on the manufacturer’s label. Connection to a different power source than those specified may result in improper operation, damage to the equipment or pose a fire hazard if the limitations are not followed. There are no operator serviceable parts inside this equipment. Service should be provided only by a qualified service technician.
PAGE 12
Compliance FCC Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation.
PAGE 13
