airFiber® X User Guide Table of Contents Table of Contents Chapter 1: Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Package Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PAGE 4
Table of Contents airFiber® X User Guide Chapter 8: Services Tab. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Ping Watchdog. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 SNMP Agent. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PAGE 5
airFiber® X User Guide Table of Contents Appendix E: Compliance Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 Installer Compliance Responsibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 airFiber AF-2X. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PAGE 6
Table of Contents iv airFiber® X User Guide Ubiquiti Networks, Inc.
PAGE 7
airFiber® X User Guide Chapter 1: Overview Chapter 1: Overview Hardware Overview Introduction Thank you for purchasing the Ubiquiti Networks® airFiber® X Carrier Backhaul Radio. This User Guide is for use with the following models: Model Description AF-2X 2.
PAGE 8
Chapter 1: Overview airFiber® X User Guide Ports Signal Level Once fully booted, the Signal 1-4 LEDs act as a bar graph showing how close the airFiber X radio is to ideal aiming. This is auto-scaled based on the link range, the antenna gains, and the configured TX power of the remote airFiber X radio. Each Signal LED has three possible states: On, Flashing, and Off. All Signal LEDs would be solidly on in an ideal link.
PAGE 9
airFiber® X User Guide Chapter 2: Installation Chapter 2: Installation Connecting Power over Ethernet Installation Requirements 1. Lift the release latch on the bottom of the airFiber X radio and slide the Port Cover off. The airFiber radio operates only with the antennas listed below.
PAGE 10
Chapter 2: Installation 4. Connect the Power Cord to the power port on the airFiber PoE Adapter. Connect the other end of the Power Cord to a power source. airFiber Configuration The instructions in this section explain how to access the airFiber Configuration Interface and configure the following settings: • Wireless Mode Configure one airFiber X radio as the Master and the other as the Slave. • Frequency Setting The operating Frequency must be the same on both the Master and the Slave. 1.
