L I M I T E D E D I T I O N User Guide
Congratulations on your purchase of the Call of Duty®: Black OPS II Earforce X-Ray headset from Turtle Beach. You now have in your possession a premium product that will bring your gaming experience to a whole new level, heightening your senses, sharpening your reflexes and enhancing your communications.
Table of Contents Package Contents 4 Feature / Function Map (Location of controls / inputs) 5 Setting Up the Transmitter 8 Using the Transmitter / Pairing Instructions 9 Using your X-Ray Headset on Xbox 360 10 Using your X-Ray Headset on PS3 12 Bluetooth Settings 13 Phone Settings 14 Surround Sound Settings 15 Recharging / Specifications 17 Equalizer (EQ) Presets/Blast Limiter Presets 18 Chat Boost™ / Variable Mic Monitor 19 Troubleshooting / Safety Notice 20 Regulatory Compliance
Package Contents D X-Ray Headset X-Ray Transmitter Turtle Beach Sticker Headset Charging Digital Optical Cable Xbox 360 Cable Talkback Cable FOR / POUR XBOX 360® | PS3™ Quick Start Guide For the full user guide, please go to http://www.turtlebeach.com/products/X-Ray Package Contents | Contenu de la boîte D X-Ray Headset Casque X-Ray X-Ray Transmitter Émetteur X-Ray T U RT L EB E ACH.
Feature / Function Map (Location of controls / inputs) X-Ray Headset - Left View 1. Power Button: Turn on the headset by pressing the power button for a couple of seconds, then release. You will hear 2 beeps and the power LED should start flashing. Turn off the headset by pressing the button until the LED stays on and you hear 2 beeps, then release. To enter Pairing Mode, press and hold the power button for about 6 seconds until you hear 2 fast beeps and the LED begins to flash rapidly (see pg 9).
Feature / Function Map (Location of controls / inputs) X-Ray Headset - Right View 1. Bluetooth® Volume: Press Chat (+) or Chat (–) to adjust Bluetooth volume level. A tone will sound each time the volume level changes. 2. Bluetooth® LED: Flashes blue once per second when paired with a device. Flashes blue twice per second when not paired with a device. Flashes blue and red quickly when in pairing mode. 3.
Feature / Function Map (Location of controls / inputs) X-Ray Transmitter 1. Digital Input LED: This LED turns on when a digital input signal is detected. When this LED is ON, the analog input is turned off. 2. Surround Sound LED: The LED will light whenever the digital input is being processed by the surround sound decoder. When this LED is off, the audio signal will be heard in stereo. 3. Dolby® Digital LED: The LED will light whenever a Dolby Digital encoded signal is detected on the digital input. 4.
Setting Up the Transmitter Xbox 360 (Slim) and PS3 1. Connect digital optical cable (DIGITAL IN) and transmitter power cables (included) to game console. NOTE: Remove the protective caps from each end of D the optical cable before inserting it into the sockets. 2. Connect to power. Digital Optical Cable (included) CONSOLE DIGITAL OUT 1 Transmitter USB Cable 2 Xbox 360 (Older Models)* 1. Connect the Digital Optical Cable(DIGITAL IN) * (Requires Xbox 360 HDMI Audio Adapter, sold separately). 2.
Using the Transmitter / Pairing Instructions The transmitter allows wireless flexibility without the restrictions of cables when using your Turtle Beach X-Ray headset. This wireless communication is through Dual Band WiFi transmitting a signal between the transmitter and your headset from up to 30 ft. If you are beyond this range or there are obstructions to the signal, you may hear a popping or clicking sound as the signal weakens and is eventually lost.
Using your X-Ray Headset on Xbox 360 Your Turtle Beach X-Ray headset is designed to work with Xbox 360 game consoles. In order to get ideal functionality from your headset, follow the directions below. 1. Go to Xbox Settings. - Choose “Settings” - Choose “System Settings” - Choose “Console Settings” - Choose “Audio” - Choose “Accessory Settings” Digital Output Current Setting Digital Stereo Dolby Digital Dolby Digital 5.1 Dolby Digital 5.1 with WMA Pro Choose the digital output type for your system.
Using your X-Ray Headset on Xbox 360 Your X-Ray headset uses a Talkback Cable (included) to connect to your Xbox 360 controller for chat. 1. Insert the “L” shaped plug into the talkback cable jack on your Xbox 360 controller. 2.
Using your X-Ray Headset on PS3 Your Turtle Beach X-Ray headset is designed to work with PS3 game consoles. In order to get ideal functionality from your headphones, follow the directions below. 1. Go to PS3 Settings 0 - Choose “Accessory Settings” 12/14 12:15 PM - Choose “Manage Bluetooth Devices” 2. Scan for Bluetooth Devices Register to manage Bluetooth® devices suchsa headsets, keyboards and mouse devices . 3.
Bluetooth Settings Pairing (Bluetooth) with a phone 1. Turn Headset ON 2. Press and hold Bluetooth Multi Function Button until LED flashes Blue and Red 2 3. Set mobile phone to Bluetooth search mode* 4. Choose “Turtle Beach X-Ray” 5. When prompted for a passcode, enter “0000.” * Each phone will differ. Refer to the user’s guide for your phone. Dual Bluetooth Pairing Turtle Beach X-Ray headphones can pair with two devices at once.
Phone Settings When your X-Ray headset is paired with your cell phone, you can make and receive calls. It can also be used with voice dialing if your phone has a voice dialing function: Making Calls 1. To make voice-dialed calls, press and hold the BT MFB button for three (3) seconds until you hear a tone. Release the button and the voice recognition function on your phone will be activated. Speak the name of the person you wish to call.
Surround Sound Settings Turtle Beach X-Ray headsets use industry standard Dolby® Digital 5.1 surround sound settings simulating 5.1 channel sound as if you were listening through a home theater system and bringing additional realism to your gaming experience. sub When a digital signal is active, the Digital Input LED surround right surround left will light and other inputs will be off. When the Surround LED lights, surround sound processing is activated. At other times, sound will be heard in stereo.
Surround Sound Settings To activate the surround sound on your X-Ray headset, follow these instructions. 1. Press SURROUND ON/OFF to turn ON the surround sound function. 2. Press the SURROUND ANGLES button on the transmitter to scroll through six (6) different presets (shown below). 3. The LED will blink in sequence to indicate which preset was selected.
Recharging / Specifications Turtle Beach X-Ray Headsets features a rechargeable lithium polymer battery that provides more than 10 hours of continuous game play. When your headset battery power is low, a tone will begin to sound every 10 seconds until the headset powers off. You can recharge your headset while still gaming with the included Headset Charging Cable. Simply plug the mini USB end into your headset CHARGE port and plug the other end into a free USB port on your game console.
Equalizer (EQ) Presets/ Blast Limiter Presets Turtle Beach X-Ray Headsets features multiple Equalizer presets to enhance your gaming audio experience. Press the TONE button on the X-Ray headset to cycle through the EQ presets as illustrated below: Equalizer (EQ) Presets: 1. Flat 2. Bass Boost 3. Treble Boost Tone Button 4. Bass and Treble Boost The Blast Limiter presets help protect your ears from deafening sounds such as explosions and gunfire by limiting the maximum level of the game sound.
Chat Boost™ / Variable Mic Monitor Chat Boost™ Chat Boost is a dynamic talkback expander built into the X-RAY headset that automatically increases chat volume during loud moments in your game, so you can always hear your teammates or other players, regardless of the game volume. Typically, if you turn up a headset’s game volume, the incoming chat level from other players could become difficult to hear over the game sound. However, with Chat Boost, as the game audio increases, the chat volume also increases.
Troubleshooting / Safety Notice TroubleShooting No sound • Check that the headset volume control is turned up. • Check that the transmitter USB power optical cables are properly connected. • Check that the headset is powered on. The LED on the left ear cup should be flashing. • Check if the LED on the front of the transmitter is on solid. If the LED is slowly pulsing, it indicates that the transmitter isn’t communicating with the headset.
Regulatory Compliance Regulatory Compliance Statements for the EAR FORCE X-RAY RX & TX Models Federal Communications Commission (FCC) Compliance Notices This section includes the following FCC statements for the EAR FORCE X-RAY RX & TX Models: - FCC ID: XGB-TB2276 & XGB-TB2271 - Class B Interference Statement - RF Radiation Exposure & Hazard Warning - Non-Modification Statement - Deployment Statement Class B Interference Statement This equipment has been tested and found to comply with the limits for a
Regulatory Compliance Canadian ICES Statements IC: 3879A- TB2290 & 3879A- TB2291 This device complies with ICES-003 and RSS-210 of Industry Canada. Operation is subject to the following two conditions: 1. This device may not cause interference, and 2. This device must accept any interference, including interference that may cause undesired operation of the device. Ce dispositif est conforme aux normes NMB003 et CNR-210 d’Industrie Canada. 1.
Declaration of Conformity Marking by this symbol: indicates compliance with the Essential Requirements of the R&TTE Directive of the European Union (1999/5/EC). This equipment meets the following conformance standards: Safety: EN 60950-1: 2006 Also Licensed for Standards: IEC 60950-1:2005, (CB Scheme Report/Certificate), UL60950-1 (NRTL License), CSA22.
LIMITED ONE YEAR WARRANTY FOR TURTLE BEACH PRODUCTS: Voyetra Turtle Beach, Inc. (“VTB”) warrants to the original end-user purchaser (“Purchaser”) that the retail Turtle Beach hardware product herein (“Product”) will be free of defects in materials and workmanship for a period of one year from the date of purchase by the Purchaser (“Warranty Period”). Any Extended Warranty or Service Plans purchased through a Retail store are not honored by VTB.
FOR / POUR Xbox 360® I PS3™ Watch Turtle Beach product training videos at: youtube.com / TurtleBeachVideos product support and warranty information: TurtleBeach.com / support Copyright © 2012 Voyetra Turtle Beach, Inc. (VTB, Inc.) All rights reserved. No part of this package may be reproduced without permission. Turtle Beach, the Turtle Beach Logo, Voyetra, Ear Force, and Engineered for Gaming are either trademarks or registered trademarks of VTB, Inc.
