Data Sheet

TECHNICAL DATA SHEET
vers ion
1.0_012018
L
W
1.5mm
L W Bundle (max.) Color pcs
100 mm 13 mm 25 mm Black 5
100 mm 13 mm 25 mm Grey 5
150 mm 13 mm 39 mm Black 5
150 mm 13 mm 39 mm Gery 5
200 mm 13 mm 55 mm Black 5
200 mm 13 mm 55 mm Grey 5
Material
Polyamide
Operating temperature -10°C ~75°C
Meilting point Hook - 230°C / Loop - 180°C
Initial 8.3N/cm²
After 1000 times 6.7N/cm²
Afer 5000 times 6N/cm²
Initial 2.5N/cm²
After 1000 times 2.1N/cm²
Afer 5000 times 1.6N/cm²
Stear strength 9.8N/cm²
Peel strength
Tensile strength
Item No.
: 201711CA004
30pcs Hook & Loop - tape assortment for bunding
This high-quality and extensive Hook & Loop tape set with 30 parts,
in three sizes and two colors in the lengths 10, 15 and 20 cm offers
extensive application possibilities. These absolutely stable Hook &
Loop tape have a very good tensile strength, are reusable and can
be locked on both sides as well as on full length. Thus, even larger
cable glands or objects can be reliably bundle or fix.
Because of this flexibility in the application Hook & Loop products
are an ideal aid in the job, hobby, household and leisure.
Further applications are found e.g. in the field of cable bundling,
fixation of plants, stage technology and much more.
Reusability makes Hook & Loop tape an environmentally friendly
alternative to traditional cable ties.
