DisplayPort to VGA Active Cable Adapter,
1920x1200/1080p (M/F), 6-in.
MODEL NUMBER: P134-06N-VGA
Description
Tripp Lite's P134-06N-VGA DisplayPort to VGA Active Cable Adapter, allows you to connect a computer with a
Displayport output to a VGA monitor. It features a simple plug and play design with an integrated chip that
converts the digital Displayport signal to analog VGA; no drivers or setup needed. Simply plug the adapter into
your Displayport source and connect your VGA cable between it and your monitor. PC video resolutions up to
1920 x 1200 are supported, as well as HD resolutions up to 1080p. Unlike passive adapters, Active adapters
convert both Single-Mode and Dual Mode (DP++) Displayport output. It is ideal for use with graphics cards, such
as AMD Eyefinity, that do not output Dual Mode (DP++) signals.
Features
Connect a VGA monitor to a computer with a Displayport output
DisplayPort to VGA Active Cable Adapter - 1920x1200/1080P (DisplayPort-Male to HD15-Female) - 6 in.
Plug and Play - no drivers or setup needed
Supports PC video resolutions up to 1920 x 1200, and HD resolutions up to 1080p
Ideal for use with graphics cards, such as AMD Eyefinity, that do not output Dual Mode (DP++) signals
Converts both Single-Mode and Dual Mode (DP++) Displayport output
Specifications
INPUT
Cable Length (ft.) 0.5
Cable Length (m) 0.2
Cable Length (in.) 6
Cable Length (cm) 15.24
Highlights
Connect a VGA monitor to a
computer with a Displayport
output
DisplayPort to VGA Active Cable
Adapter - 1920x1200/1080P
(DisplayPort-Male to
HD15-Female) - 6 in.
Plug and Play - no drivers or
setup needed
Supports PC video resolutions up
to 1920 x 1200, and HD
resolutions up to 1080p
Ideal for use with graphics cards,
such as AMD Eyefinity, that do
not output Dual Mode (DP++)
signals
Converts both Single-Mode and
Dual Mode (DP++) Displayport
output
System Requirements
Computer with a Displayport
output
Monitor with a VGA port
Not for use with MST Hubs. For
compatibility with MST Hubs, use
a Displayport 1.2 compliant
product such as
P134-06N-VGA-V2
Package Includes
DisplayPort to VGA Active Cable
Adapter - 1920x1200/1080P
(DisplayPort-Male to
HD15-Female) - 6 in.
1 / 2
