Quick Installation Guide J Series/ M Series /S Series IP Security Camera For a complete product manual and installation software, please visit TOPODOME official website. www.topodome.
Topodome Quick Installation Guide QIG-En-V1.0 General Introduction Topodome IP Security Cameras include J series, M series and S series products. These cameras can be installed in various places, walls, backyards, indoors and corridors. These series of products can be viewed with the same mobile APP or computer software, providing customers with convenient and safe services. These series of products support wired and wireless connections. It should be noted that wireless connections only support 2.
Topodome Quick Installation Guide QIG-En-V1.0 Physical Description S- Series Overview J- Series Overview M- Series Overview ● The above figures are for reference only, the actual products appearance maybe different. www.topodome.com 2 Tech support email support@topodome.
Topodome Quick Installation Guide QIG-En-V1.0 Important Tips: 1.The suitable use environment temperature is -20 to 60 degrees Celsius, please avoid using in an environment that exceeds this range. 2.These products only support 2.4G wireless network. Please make sure that your wireless router supports 2.4G wireless and does not activate MAC filtering (For Mac address of camera, please refer to 3.1 section) or firewall.
Topodome Quick Installation Guide QIG-En-V1.0 Start Installation of the Camera These cameras can be installed by a smartphone/ tablet (Android or iOS), or by a PC (Windows or Mac OS). Please finish the hardware installation first and begin the software configuration refer to the below guide. 1. Hardware installation 1.1 Mount the Wi-Fi antenna and make it stand vertically. 1.2 Connect the camera’s DC socket with the power adapter, the camera will turn on automatically. 1.
Topodome Quick Installation Guide QIG-En-V1.0 1.4 During the camera configuration process, if you use a mobile phone or tablet device, you can choose to connect the camera to the router with a network cable, or choose not to connect the network cable. Instead, connect the camera's hotspot first, and then set up a wireless connection with the router. 1.5 If you are using a PC for configuration, you must connect the camera to the router with a network cable (you can find the network cable in the gift box).
Topodome Quick Installation Guide QIG-En-V1.0 2. Smart Phone Installation Method 2.1 Download and Install CamHi Pro App. Search "CamHiPro" on App Store or Google Play, or scan the QR code to download CamHiPro App and install it on your Phone/ Tablet. Scan the left QR code to directly download the iOS App from App Store Scan the left QR code to directly download the Android App from Google Play 2.2 Add Camera to Your Phone and Login the Camera. www.topodome.com 6 Tech support email support@topodome.
Topodome Quick Installation Guide QIG-En-V1.0 Run the CamHiPro App on the phone. Tap "Click Add Camera", then tap "IP camera". 2.2.1 If it is for the first installation, go to "New device", then tap "Power is on, next step". Here you can choose "Connected network Cable" or "Not connected the network cable". -Connected network Cable: a.
Topodome Quick Installation Guide QIG-En-V1.0 yours, input the WIFI password, then tap "Configure wireless and add". Fig2.1 Wireless configuration d. When WiFi configuration is successful, you can choose Camera Name from default options or input yours. e. If you decide not to configure the Wireless and click the "Not configured yet, add directly", will skip the configuration of WiFi, you have to finish this step later in camera settings when you want to connect to the router via wireless mode . www.
Topodome Quick Installation Guide f. QIG-En-V1.0 Now the camera device page will appear, please tap the Video Windows of the camera and enter the Control Panel of your camera. g. In the Control Panel, you can implement functions such as video recording, screenshots, two-way voice and image adjustment. If your camera model supports PTZ, then you can achieve rotation and zoom functions.
Topodome Quick Installation Guide b. QIG-En-V1.0 For Android phones, next step will display "Discover device hotspots" , and WiFi hotspot "IPCAM-xxxxxx" will appear in the hotspots list (xxxxxx is same as the UID middle number, Fig1.3), default password is "01234567". It is recommended to connect to the hotspot manually. Fig2.3 Hotspots Connection c. For Apple phones, next step will display the guide of how to connect the hotspot step by step.
Topodome Quick Installation Guide QIG-En-V1.0 input device login information, username and password (both are "admin" for factory default setting). e. Click "Add to", the "Wireless configuration" page will pop, please finish this step refer to Fig1.4, the camera will play music when connected to the router successfully. f. Name your camera and go to the camera list page, tap the camera you have added, enter Control Panel to operate the camera (more details please refer to the manual book on the www.
Topodome Quick Installation Guide QIG-En-V1.0 is successful, Congratulations! Fig2.4 Add camera in use 2.3 Change the default Password of the Camera For security reasons, after the installation is complete, it is strongly recommended that you modify the default login password. You can modify it through the mobile App or through the browser. The mobile APP only allows you to modify the login password, and the login username and password can be modified simultaneously on the browser. www.topodome.
Topodome Quick Installation Guide QIG-En-V1.0 Click here and enter camera function settings Fig2.5 Camera settings Tap the "Gear Icon" in the camera panel, the function settings page will pop out, go to the "Change Password" option, input your new password and tap "Apply". Caution: ①Changing password or username will force the camera offline on phones or PCs, users have to login again with a new password or username.
Topodome Quick Installation Guide QIG-En-V1.0 2.4 Modify Wireless Configuration via App You can modify the WIFI configuration via APP anytime. Go to "functions settings", tap "Wireless setting". a. You can get the Wi-Fi list near your device, if you want to change a new Wi-Fi network, just choose the new SSID and input the login password to connect again. b. If you have modified the login password of the old WiFi network, then the camera will offline.
Topodome Quick Installation Guide QIG-En-V1.0 3. Personal Computer Installation Method If you want to install the camera by a PC for the first time, please finish the hardware installation. Refer to Fig1.1 and Fig1.2 (connect a network cable to router and power on). 3.1 Find IP address of the Camera Please download the software of "Search Tool" from www.topodome.com/support and install it on PC. A shortcut icon will appear on the desktop.
Topodome Quick Installation Guide QIG-En-V1.0 3.2 Install the camera with CMS Software 1. Please download the CMS software from the URL of www.topodome.com/support, the software named HiP2P Client. 2. After the CMS software is installed, a shortcut will appear on the desktop. Double click and run the software. 3. Click the green "+" button at the top of the main screen, a login window will pop up, please keep the password area empty (there is No default password), and then www.topodome.
Topodome Quick Installation Guide QIG-En-V1.0 click "OK" to log in to the software. 4. When the software starts, it will automatically search and add all cameras in the local area network. If the default username and password of the camera are still "admin", the camera will be added automatically; if the username and password of the camera have been modified, the software will display "password error", you need to manually modify the password and complete the installation. 5.
Topodome Quick Installation Guide 7. QIG-En-V1.0 Add New Device: If the camera is not in the LAN, you need to directly add the UID to connect, click the "Input UID" button, then manually enter the UID of new camera, input right username and password, click "OK" and the new camera will be added to camera list. 8. Now you have successfully completed the installation of the camera on CMS software, and then you can view the camera, or set PTZ,Preset,Image setting etc. 9.
Topodome Quick Installation Guide QIG-En-V1.0 "admin" and default password "admin". 4. For IE11 and edge browsers, when the camera is installed for the first time, a plug-in installation prompt will appear.The name of the plug-in is ClientPlusSetup. If there is no prompt, you can click "Setup software" on the login page to start the plug-in installation.
Topodome Quick Installation Guide QIG-En-V1.0 3.4 Wireless Connection Setup via Browser 1. Click the menu Settings on the top of the live view window, go to the option Network-->Wireless, first select Enable Wireless, then click the search button, all WiFi names around the camera will be displayed, please choose the WiFi name you want to connect and input the login password of WiFi. 2. The wireless login password needs to be entered twice.
Topodome Quick Installation Guide QIG-En-V1.0 Frequently Asked Questions Q1: Why does the program prompt me with "wrong password" even though I tried different username and password several times? A1: ①The original username and password are both "admin" (lowercase, no capital letters) as factory default setting. If the camera has been installed before, the password may have been changed. Please enter the new password to log in.
Topodome Quick Installation Guide QIG-En-V1.0 ) and symbols (@#&...). If you use these characters in the SSID and WiFi password, the wireless configuration will be invalid. Please use regular English characters and numbers. In addition, please make sure that your wireless router does not use AES+TKIP encryption, and the camera cannot support this wireless encryption mode.
Topodome Quick Installation Guide QIG-En-V1.0 Please set the appropriate sensitivity and set an alarm area (such as in front of the door), so that motion detection can work more effectively. In addition, when the weather changes and there is rain or snow, the camera's motion detection function will be disturbed.
Topodome Quick Installation Guide QIG-En-V1.0 please check whether the wireless signal is higher than 70% or whether the antenna is loose; in addition, if you want to obtain smooth image quality, the required network bandwidth is at least 2Mbps; in addition, you can find the "HD" or "SD" Symbol on the video window, please tap it and choose "SD" to select the smooth mode.
www.topodome.com TOPODOME is trademark of TUOSHIJIA Corp., registered in main countries including USA, UK and EU.
