User Guide
– user guide © 2001 by Bachstraße 59, 5023 Salzburg – Austria www.orderman.com Rights of modification reserved. Duplication of this guide or parts thereof is permitted only with a written agreement of think dig. P3.45-247 V1.0 · · · · think dig does not assume any liability or legal responsibility for omissions or errors in this guide. think dig does not assume any liability for any loss or claims of third persons, that are caused by the use of this guide.
– user guide Contents ORDERMAN DON overview .......................…………………....... 4 Back view of ORDERMAN DON........................................... 5 General Parts included, warranty.....................................……………... 6 Correct handling Safety precautions, care of the unit...........................……… 7 Battery use Charging and exchanging...........................……………………….. 8 Getting started............................................................……... 9 Setup-menu Display-settings....
– user guide ORDERMAN DON overview Ordercard reader – optional (integrated in the housing) On/Off button touch-Display fax-function power Off-function printing function touch-pad – menu card area connection for the power supply unit charging contacts for the charging station (optional) 4
– user guide Back view of ORDERMAN DON release button for battery menu card holder release area type plate aperture for mounting the cord-holder 5
– user guide General information Welcome to the world of ORDERMAN DON Think dig, the company, is among the top international developers and manufacturers of hand-held wireless terminals for the hospitality industry. By purchasing ORDERMAN DON you have acquired a quality product, that brings you future technology today. The use of this product will also bring your company many financial as well as operational advantages. ORDERMAN DON has been specially developed for the hospitality industry.
– user guide Correct handling Safety precautions ORDERMAN DON should be used only with an ORDERMAN DON battery resp. with an ORDERMAN DON power supply unit and with the entry pen of the ORDERMAN DON touch pen. ORDERMAN DON should never be exposed to rain, hail or snow. If the unit gets damaged, it must be checked by your ORDERMAN dealer for possible defects. The touch-area of the unit is made of glass, and should therefore be treated carefully.
– user guide Battery use Charging Connect the original power supply unit to the underside of the ORDERMAN DON (see also page 4). The charging procedure of the battery (accumulator) inside the unit is shown by the filling battery symbol. A complete charging procedure takes about 4 hours. The unit can be used during this charging operation. You may also charge the battery separately from the unit, using the ORDERMAN DON charging station (optional). This charging process takes about 60 minutes.
– user guide Getting started To start the operation with ORDERMAN DON, insert the battery and press the On/Off-Button. Before the first operation, it is advisable to do a complete charge of the battery (see page 8). After having switched on the unit for the first time, you get the information of the version of the operating system.
– user guide SETUP– Menu Touch Calib. Display Power Password SAVE QUIT In the menu Setup, you can do the touch-calibration in the sub-menu Touch-Calib. (see also the following describtion). In the sub-menu Display you can change the contrast of the display. The refresh-rate with 81 Hz is a standard setting. In the sub-menu Power you can change the automatic-power-off-time for the backlight and also for the unit.
– user guide Change of the ORDERMAN DON menu card The changing of the ORDERMAN DON menu card has to be done in a clean and dry place. Switch off the unit and take out the battery. 2. unlock direction 1. unlock point menu card holder With the end of the entry pen of your ORDERMAN DON touch pen you have to press on to the unlock point. With a simultaneous motion in the unlock-direction, the menu card holder comes out of the housing and can be taken out of the unit.
– user guide Technical data frequency range operating frequency range 902.100 MHz -905.000 MHz 902.100 MHz -905.000 MHz radio capacity data transmission lower than 1mW bi-directional, licence free operation range inndoors: up to 50m outdoors: up to 300m indoor area coverage: up to 7800 sq.m power supply: battery (accumulator): lithium-Ion technology, 3.6V, 750mAh or Power supply unit: 7.5V, 800mA Power supply unit: - input voltage - max.
– user guide Radio certification 13
– user guide Declaration of conformity Declaration of Conformity In accordance with EC Directive - R&TTE Directice 1999/5/EC Radio and Telecommunications Terminal Equipment Elektromagnetic Compatibility 89/336/EWG amended by 93/31/EWG The Device ORDERMANÒ OM-DON Is developed, designed and manufactured in accordance with the above mentioned EC – guideline under the sole responsibility of Fa.
– user guide FAQs – frequently asked questions - Touch misfunction – bad calibration: By pressing the On-button several times, you arrive at the touch-calibration menu, where you can do a new calibration (see also page 10).
