Technical Description and Operating Instructions Concept C 200 Black Edition 2.
Contents General notes and information.......................................................................................................................................3 Safety notes...................................................................................................................................................................4 Caution icons.................................................................................................................................................
General notes and information Notice Contact The information in this document may change without prior notice and in no way constitutes any liability on the part of Lautsprecher Teufel GmbH. No part of these instructions may be reproduced in any form or be broadcasted in any way electronically, mechanically, by photocopy or recording without the written permission of Lautsprecher Teufel GmbH.
Safety notes Caution icons You will find the following caution icons in these instructions: Danger High risk! Failure to observe the warning may result in severe personal injury or death. Attention Moderate risk! Failure to observe the warning may result in property damage. Minor risk! Points which should be observed when handling the unit. Safety notes Gefahr Risk of electric shock! Faulty installation of electrical equipment or mains voltage which is too high can cause electric shocks.
Danger Risk of injury An unstable base may cause the unit to tip and injure or even kill persons, children are particularly at risk. You can prevent many accidents by taking the following precautions. • Only place the subwoofer on the floor. • If you want to use underframes or speaker stands, only use those recommended by the manufacturer. • When storing the product, also ensure that it stands safely and that it cannot be knocked down or over. Explanation of symbols Protection class II Fuse 3.
Overview b a c d Product Contents a 1 x subwoofer CC 202 SW b 2 x satellite speaker CS 25 FCR c 2 x table stand for satellite e d 2 x screw for table stand e 1 x mains cord f 1 x desktop remote control Check to be sure • Check that all items have been delivered and that nothing is damaged. • If the delivery is incomplete or you find damage sustained in transit, do not operate the unit but contact our service department (see page 3).
Controls and connections Pos Name 1 1 Front 2 Standby Description Switch the unit on or to standby mode 2 – Bass speaker 3 – Reflex opening 3 Pos Name 4 5 6 Rear 7 8 9 Satellite Desktop remote control Description 4 LINE IN RCA jacks for connecting to an audio source 5 REMOTE CONTROL Jack for remote control f 6 USB USB port for connection to a PC.
Setup and connection Setup location Wall mounting • Preferably, the room, where you plan to use a Concept C 200, should not be larger than 25 sqm. • Select a stable, level base. • Make sure that the environment is clean and free from dust. • Avoid placing the unit close to sources of heat or in direct sunlight. • Arrange the connecting cables so that they do not pose a trip hazard. • Do not place any heavy objects on top of the cables or units.
Split the cables down to approximately 30 mm on both ends and strip approximately 10 mm of insulation on the respective cores. Twist the cables so that no cores are protruding. Push down the lever for the connector terminal 12 on the satellites and insert the stripped cable end into the opening below the respective connector terminal. The cable is clamped in place when the lever is released. • Connect the terminal 6 USB with a free USB port on your computer (all USB standards are supported).
Use Activating and deactivating Tabletop remote control A B C 8 • Using the mains switch 8, you can activate or deactivate your Concept C 200. In standby mode and LED 1 is red. 1 • With the button 1 “Standby” or 14 “Power”, you can switch your Concept C 200 to operating and/or standby mode. In operating mode, the LED 1 is blue. Automatic shutdown If there is no audio signal for 20 minutes, the subwoofer switches to standby automatically.
Care an cleaning Clean your Concept C 200 regularly with a soft, slightly damp microfibre cloth. Please be absolutely sure to observe the following: Danger Risk of electric shock! In contact with live parts water can lead to electric shock or short circuit. • Ensure that no water gets into the unit. • Disconnect the device from the mains power supply before cleaning. Attention Risk of damage! Using the wrong cleaning materials may damage the delicate surface of the case.
Protecting the environment Batteries and rechargeable batteries Disposal of the unit Do not dispose of batteries or rechargeable batteries in household waste! Every consumer is required by law to dispose of batteries and rechargeable batteries, whether they contain hazardous materials*) or not, at a local authority or in-store collection point so that they can be disposed of in a manner which is not dangerous to the environment.
