rt /0 ific 2/ a 06 te U 17 s e :0 9 Version: 1.00 Reference No.: PT-CU-P2-00-17100UEN Date: January 24, 2017 20 17 BV Ce CAREU P2 Personal Tracker User Guide SYSTEMS & TECHNOLOGY CORP.
General Information Disclaimer rt /0 ific 2/ a 06 te U 17 s e :0 9 If any breakdown occurs due to the operation of the described product or users’ improper handling in accordance with the instructions of the document, SYSTECH shall be liable for the General Conditions based on the delivery of the described product and the content of the document.
rt /0 ific 2/ a 06 te U 17 s e :0 9 Table of Content Chapter 1. Introduction .................................................................................................... 1 1.1. About this Document ......................................................................................................1 Chapter 2. The Device ....................................................................................................... 2 2.1. Specification ...................................................
CAREU P2 Personal Tracker User Guide Chapter 1. Introduction rt /0 ific 2/ a 06 te U 17 s e :0 9 The CAREU P2 Personal Tracker integrates GSM and GPS tracking services to provide monitoring care for the elderly and children by mobile applications.
CAREU P2 Personal Tracker User Guide Chapter 2. The Device 2.1. Specification • • • • • • Weight: 76g GPS Receiver: 72 Channels or Above Datum: WGS-84 Power Source: 5V DC Operating Temperature: Charge: 0℃ ~ +40℃; Discharge: 0℃ ~ +60℃ Communications: GSM 850/900/1800/1900 ,WCDMA 800/850/900/1900/2100 , Voice, SMS, GPRS TCP/UDP • Back-Up Battery: 770mA Lithium-Ion Battery • IP65 Water Proof 2.2. Device Outlook 1. 2. 3. 4. 5. 6. 7. 8. 9.
CAREU P2 Personal Tracker User Guide • Notification LED rt /0 ific 2/ a 06 te U 17 s e :0 9 1. Power LED: Red lights • Red: Charging • OFF: Fully charged / Discharging 2. GSM LED: Blue light • Flashing (once every 3 seconds): Searching signals • Flashing (once every 10 seconds): Receiving signals normally. 3. GPS LED: Yellow light • Flashing (once every 3 seconds): Searching signals in normal mode • Flashing (once every 10 seconds): Searching signals in A-GPS mode 4.
CAREU P2 Personal Tracker User Guide Note: Before installing the SIM card, be sure to remove SIM protection (PIN code) with a mobile phone. rt /0 ific 2/ a 06 te U 17 s e :0 9 • Remove the plastic strip from the battery. 17 BV Ce • Place the battery into the battery compartment. • Restore the back cover to its original position. 20 Note: Before restoring the back cover, make sure the SIM card and battery are installed properly in place. • Optional: Place the CAREU P2 into the jelly case cover.
CAREU P2 Personal Tracker User Guide • Power Off rt /0 ific 2/ a 06 te U 17 s e :0 9 To power off CAREU P2, press and hold the Power Button for 2 seconds. The CAREU P2 will make a long beep and power off. 3. Charge the device • You may charge CAREU P2 through the Micro USB port at the bottom of the device. Or • Charge CAREU P2 through the optional CAREU P2 Station. 20 17 BV Ce • Charger output specification 5V@1A required.
CAREU P2 Personal Tracker User Guide Chapter 3. Getting Started with CAREU P2 rt /0 ific 2/ a 06 te U 17 s e :0 9 3.1 Device Configuration In Windows OS, open HyperTerminal, or similar terminal console program. 2. If you are prompted to input the information of your location, complete them to proceed. 3. On the File menu of HyperTerminal, click New Connection. 4. In the Name box, type a name that describes the connection. In the Icon box, click an appropriate icon. Press the OK button to proceed.
CAREU P2 Personal Tracker User Guide rt /0 ific 2/ a 06 te U 17 s e :0 9 In the connection that you have just set up, click File | Properties. Select the [Connect To] tab. From the [Connect using] drop down list, select the correct com port by checking Window’s [DeviceManager]. 20 17 BV Ce 6.
CAREU P2 Personal Tracker User Guide In the File menu, click Properties. Click the [Settings] tab. Press the ASCII Setup button. 8. In the [ASCII Sending] group box. Select both Send line ends with line feeds and Echo typed characters locally. Press the OK button. 20 17 BV Ce rt /0 ific 2/ a 06 te U 17 s e :0 9 7.
CAREU P2 Personal Tracker User Guide rt /0 ific 2/ a 06 te U 17 s e :0 9 Connect CAREU P2 and Power ON. Ce 9. 20 17 BV 10. In t he [HyperTerminal] window, type in the command "AT$VERSION?" and press the Enter key. The hardware and firmware version will show. As long as your [HyperTerminal] window appears as the screenshot below, a connection between the device and your system has already been built up and working. It is time to send all configuration commands.
CAREU P2 Personal Tracker User Guide 3.2 Communication Settings 1. rt /0 ific 2/ a 06 te U 17 s e :0 9 The CAREU P2 communicates with your control center by either SMS or GPRS (TCP/UDP). SMS Configuration Use AT$SMSDST command to set a SMS control center phone number or short code.
CAREU P2 Personal Tracker User Guide 3.3 GPS Tracking Configurations After the device communication settings are done, the GPS tracking function is then ready to For example, rt /0 ific 2/ a 06 te U 17 s e :0 9 operate. The setting of GPS tracking can be done by using AT$PDSR command. AT$PDSR=1,300,25,0,2,0,0,1,1(Tracking through GPRS by time interval 300 seconds) For simple testing of GPRS, run the TCP Server U-Series software which is provided by 17 BV Ce SYSTECH.
CAREU P2 Personal Tracker User Guide Chapter 4. Using the CAREU P2 4.1. Self Geo-fencing rt /0 ific 2/ a 06 te U 17 s e :0 9 This chapter will guide you to major functions of CAREU P2 and necessary settings to operate the device. The device user may define the Geo Fence radius through protocol command (AT$SGF, default 100m), after triggering the Geo-fencing button, CAREU P2 will use its last known fixed GPS location as the center to create a circular fence.
CAREU P2 Personal Tracker User Guide Write Command: OK：SGF rt /0 ific 2/ a 06 te U 17 s e :0 9 Read Command: Return Value OK：SGF $SGF=,< Entry Time >,< Exit Time > Error Response: ERROR：SGF AT$SGF=100,20,20 OK:SGF Example AT$SGF? OK:SGF $SGF=100,20,20 Note AT$SGFEN Self Geo-fence alert enable Description This command is used to set/query the Self Geo-Fence enable settings.
CAREU P2 Personal Tracker User Guide Write Command: OK：SGFEN Return Value rt /0 ific 2/ a 06 te U 17 s e :0 9 Read Command: OK：SGFEN $SGF=< Option >,< Action >,< Force Connection > Error Response: ERROR：SGFEN AT$SGFEN=1,3,1 OK:SGFEN AT$SGFEN? OK:SGFEN $SGFEN=1,3,1 Example 20 17 BV Ce Note 14
CAREU P2 Personal Tracker User Guide 4.2. Positioning AT$PDSR Description Syntax rt /0 ific 2/ a 06 te U 17 s e :0 9 Setting regular timed interval or distance travelled interval reports. Position and device status reporting settings Position and data shall be reported when the device is moving. Reporting shall be based upon satisfying a minimum time requirement and minimum distance requirement Write Command: AT$PDSR=,,
CAREU P2 Personal Tracker User Guide rt /0 ific 2/ a 06 te U 17 s e :0 9 Return Value Write Command: OK：PDSR Read Command: OK：PDSR $PDSR=,,,< Reserve >, ,< Reserve >,,
CAREU P2 Personal Tracker User Guide 4.3. Unusual Collision Alarm The CAREU P2 is integrated with a 3-axis G sensor to detect any unusual collision. rt /0 ific 2/ a 06 te U 17 s e :0 9 To enable and disable the alarm for unusual collision: • Enable / Disable Unusual Collision Alarm: AT$DOWN Man Down Detection settings This command is used to set/query man down threshold settings. Man down is described as an abrupt change in velocity as might be experienced during a wreck.
CAREU P2 Personal Tracker User Guide rt /0 ific 2/ a 06 te U 17 s e :0 9 1 – Logging When the alert condition is true, log the most recent GPS position to non-volatile flash memory for future retrieval. 2 – Polling When the alert condition is true, send the latest GPS position to the remote base station. 3 – Logging + polling When the alert condition is true, log the most recent GPS position to non-volatile flash memory and send the latest GPS position to the remote base station.
CAREU P2 Personal Tracker User Guide SOS Alert • Press and hold the SOS Button for 2 seconds, the CAREU P2 will beep 4 times. Within 10 seconds time, if the user presses and holds the Geo-fencing button for 2 seconds, CAREU P2 will make a long beep once and cancels the SOS alert event. If no cancellation action takes place within 10 seconds time, the SOS event then becomes valid and proceeds to alert actions.
CAREU P2 Personal Tracker User Guide 4.5. Bluetooth (BLE) rt /0 ific 2/ a 06 te U 17 s e :0 9 When BLE function is enabled, an alert report is generated if CAREU P2 is out of the P2 Station proximity range. A separate alert report is also generated when CAREU P2 is once again within the P2 Station proximity range. BLE function related Protocol Commands AT$BLEEN BLE alert enable Description This command is used to set/query the BLE enable settings.
CAREU P2 Personal Tracker User Guide 4.6. P2 Station Specification rt /0 ific 2/ a 06 te U 17 s e :0 9 • Weight: 80g • Power Source: 5V DC (via Micro USB) • Operating Temperature: -20℃ ~+60℃ 17 BV Ce 4.6.1 P2 Station Outlook Set Bluetooth Button 2. Mode Button 20 1. 3. LEDS status Indicator A. Backup battery slot charged LED (solid light when fully charged) B. Backup battery slot charging status LED (solid light when battery is charging) C.
CAREU P2 Personal Tracker User Guide 4.6.2 P2 Station Pairing rt /0 ific 2/ a 06 te U 17 s e :0 9 Upon powering up the P2 Station, the station automatically enters Scanning Mode to scan within its proximity for all previously paired CAREU P2 units. When a CAREU P2 unit is already paired, the number LED on the P2 Station lights up. The different numbering of LED lights also indicate which CAREU P2 unit is currently connected to the P2 Station. One P2 Station may pair up to maximum 4 units of CAREU P2.
CAREU P2 Personal Tracker User Guide Chapter 5. About Systems & Technology Corp. rt /0 ific 2/ a 06 te U 17 s e :0 9 The CAREU P2 Personal Tracker is produced by Systems & Technology Corporation. The company is a key developer and supplier of advanced systems in tracking solutions, geographical information systems and navigation systems. If you need the information about other products, please contact us by phone or by fax as listed below, or visit our websites.
CAREU P2 Personal Tracker User Guide Chapter 6. Declaration rt /0 ific 2/ a 06 te U 17 s e :0 9 As the CAREU P2 Personal Tracker works based on GPS (Global Positioning System) and GSM (Global System for Mobile Communication), it has to work with normal GSM and GPS conditions. Performance of the CAREU P2 is liable to the following: • • Weak GPS satellite signals: The positioning quality will be affected. Weak GSM signals: The report quality of CAREU P2 will be affected.
CAREU P2 Personal Tracker User Guide Chapter 7. Regulations • This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. • This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules.
