sWiFi/all User Manual Version 1.0 2020.04.
sWiFi/all User Manual Revision History Revision Date Version Pages Description 04/06/2020 1.0 All New Copyright 2006-2016 SystemBase Co., Ltd. All rights reserved. Websites http://www.sysbas.com/ Phone +82-2-855-0501 Fax +82-2-855-0580 16F Daerung Post Tower-1, 288, Digital-ro, Guro-gu, Seoul, Republic of Korea (Postal code 08390) For any inquiries or comments, please contact our technical support department. tech@sysbas.
sWiFi/all User Manual 목차 CONTENTS 1. OVERVIEW .......................................................................................................................... 3 1. Package ................................................................................................................................................................................... 3 2. Operating Environment..........................................................................................................................
sWiFi/all User Manual 목차 5.4 View Settings..................................................................................................................................................................... 9 5.5 Setting Description ......................................................................................................................................................
sWiFi/all User Manual 1. Overview 1. OVERVIEW sWiFi/all is an ultra-small Serial to WiFi Converter that connects various kinds of serial equipment to WiFi wireless network. It uses wireless 2.4Ghz Band and 5Ghz Band, supports IEEE 802.11 a/b/g/n communication standards. 1. PACKAGE sWiFi/all 5V DC Adaptor sWiFi/all User Manual 2. OPERATING ENVIRONMENT As the number of sWiFi/all increases, the more high-performance CPU and high-capacity memory is required.
sWiFi/all User Manual 2. Specification 2. SPECIFICATION sWiFi/all is an ultra-small serial converter that provides WiFi wireless connectivity function to equipment supporting RS232, RS422, RS485. The communication specification supports 2.4GHz, 5GHz IEEE 802.11 a/b/g/n and supports standard serial communication. sWiFi/all connects various kinds of serial equipment to the network, including remote control and monitoring of devices connected through the network.
sWiFi/all User Manual 2. Specification 2.2 COM Redirector Mode The serial port of sWiFi/all connected to the network can be used as if were a serial port mounted on a PC.
sWiFi/all User Manual 3. Hardware Configuration 3. HARDWARE CONFIGURATION 3.1 sWiFi/all Appearance sWiFi/all is a DCE(Data Communications Equipment) type converter that connects directly to DTE equipment such as PCs. Pressing the factory reset button for more than 3 seconds will reset the sWiFi/all to the default state.
sWiFi/all User Manual 3. Hardware Configuration 3.2 Serial Port (DE-9 FEMALE) DTR TXD GND RXD Pin No. Signal Description 2 RXD Receive Data (Input) 3 TXD Transmit Data (Output) 4 DTR Data Terminal Ready (Output) 5 GND Ground 6 DSR Data Set Ready (input) CTS 7 RTS Request to Send (Output) RTS 8 CTS Clear to Send (Input) 5 2 3 4 8 9 7 1 6 DSR RS-232 3.
sWiFi/all User Manual 5. Console Setting 4. HOW TO CONNECT This chapter provides information necessary for sWiFi/all to connect and operate with the desired serial devices, such as wireless LAN and serial connection. Procedure for connecting sWiFi/all to devices and networks is as follows. 4.1 Power Supply Check that the input voltage supplied to sWiFi/all matches the model’s specification and supply the voltage. sWiFi/all starts booting with power on only when power is normally supplied.
sWiFi/all User Manual 5. Utility Setting 5. SETTING IN UTILITY sWiFi/all provides a setup method through sWiFiConfig.exe utility. 5.1 Mode Setting The initial sWiFi/all serial port settings are 9,600bps, 8bit, 1stop, no parity. 5.2 Setting Click the Supply Config button to change the sWiFi/all settings. The data set at this time will be stored in sWiFi/all and with the reset of sWiFi/all, it will work in the changed settings. 5.
sWiFi/all User Manual 5. Utility Setting 5.4 View Settings Click the ReadConfig button in the program to view the current setup status of sWiFi/all. You can view or execute console commands through the console window at the bottom of the program.
sWiFi/all User Manual 5. Utility Setting 5.5 Setting Description Sub Default command Description Set the operating protocol to be used on the serial port. com_redirector Make the serial port on CS sWiFi/all available as a virtual COM port on a PC in Windows 2000/XP/2003/Vista/7/8.1 environment. When this mode is selected, all settings in the serial will follow the virtual COM Port settings. tcp_server CS sWiFi/all acts as a socket server and waits for access from the client on the network.
sWiFi/all User Manual Sub 5. Utility Setting Default command Description the socket at once. For example, if a serial device transmits 100 bytes of text from a serial device to a socket on the server via CS sWiFi/all, if the value is 0, the data entered in bytes at a time is immediately sent to the server through the socket, ensuring real time, but causing a lot of traffic to the network. This can lead to poor performance of the product, leading to loss of serial port data, so avoid setting to 0.
sWiFi/all User Manual 5. Utility Setting FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
sWiFi/all User Manual 5. Utility Setting and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
