Car DVR Model: VA-CD001 SKU: 28-25001-001 Car DVR User Guide Thank you for choosing the Car DVR. Please read this user manual carefully, and keep it for future reference. If you have any questions or concerns, please contact our customer support team by email at support.info@vava.com.
8 9 10 14 15 12 11 13 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ Car Mount Micro USB Port Magnet Blue/Red double color LED Light (Power / Work Status) White LED Light (WiFi Status) Reset Button Micro SD Card Slot Snapshot Button GPS Module Micro USB Cable VAVA Power Bank (With Charger) Power Button LED Status Indicator LED Battery Indicator USB Port of the Power Bank Specifications CPU NT96660 Vision Processor Sony IMX291, 1/2.8 in Lens Full 6G + 1 IR lens Angle 140°F1.
G-Sensor 3-axis accelerometer Resolution 1920*1080/60fps (Default); 1920*1080/30fps; 1280*720/30fps; 840*480/30fps Storage Supports up to 128GB, Class 10 TF Card Connection WiFi for phone and dash cam connection 2.
Installing the Car DVR 1. 2. 3. 4. 5. 6. 7. Insert the TF card into the micro SD card slot. Stick the car mount onto your car windshield (ideally right in the middle). Fix the Car DVR onto the mount via the magnet. Connect the USB cable to the micro USB port of the dash cam, run the cable along the edge of the windshield, tuck it away in the seams, all the way to the USB port of the power bank (Keep away from the airbag area).
charger is disabled and power to the Car DVR is then provided by the power bank. 2. There will be 3 minutes for your choosing. When you want the dash cam keeping working, you should long press the button on the power bank for 3 seconds, then the dash cam will keep on working about 30 minutes.
Once your phone is connected to the camera, you can modify the camera settings, including resolution, volume, mute, micro SD card management, firmware update, etc. Attention Our apps and camera firmware will be updated regularly, you can update the firmware via apps. Do not use cardboard, paper towel, or napkin to clean the lens. Do not attempt to repair, dismantle, or modify the dash camera hardware by yourself. When no longer needed, dispose of the dash camera according to local policies.
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
