ITEM NO.: A102009000 WE HAVE YOU IN MIND, LET US SERVE YOU! Questions? Issues? CONTACT US 24 hours / 7 days a week www.sunjoyonline.com customer.care@sunjoygroup.com 1-(866)-578-6569 The beaaring capacty of the top snow is 600 pounds .When the snow is more than 10 inches,please clean the snow in time.
/ 10 Safety Information two people are required for this assembly. Some parts may contain sharp edges. Wear DANGER: This unit is heavy! Do not assemble this item alone. protective gloves. When assembling and using this product, WARNING: Do not leave the gazebo where there basic safety precautions should always be is a risk of high wind, as possible damage will followed to reduce the risk of personal occur to the structure. injury and damage to equipment.
/ 10 Parts List Description Part# Post P000200490 A 4 Stake slice P000100351 B 4 P005600327 D1 4 P005600328 D2 4 Corner Beam P000601532 E 4 Middle Beam P000601533 F 4 P000501291 G 4 Left Slot P000900108 H1 4 Right Slot P000900109 H2 4 “F”Baffle 1 P005600329 I1 4 “F”Baffle 2 P005600330 I2 4 P005000449 J1 4 P005000450 J2 4 Corner Support P005000448 K 4 Small Roof Cover P000800272 L 1 Roof connector P000501290 M 1 Hook P005800001 N 1 P000501292
/ 10 Upper Closure plate Middle Closure plate Left small PC board Left Big PC board Right small PC board Right big PC board Netting P005600333 Q1 4 P005600334 Q2 4 P000700677 R1 4 P000700679 R2 4 P000700678 R4 4 P000700680 R5 4 P001200229 S 1 Hardware Pack 1 AA H010110039 M6X20 Bolt 68 PCS BB H050010057 M6 Flat Washer 108 PCS CC H010020013 Bolt M6X35 16 PCS DD H030040032 Bolt M5X15 32 PCS EE H010020011 Bolt M6*15 32 PCS WW H090010002 M6 Wrench 1 PCS Country
/ 10 Fig.1: Attach stake slice(B) on post(A) and fix them tightly by bolt(AA) and flat washer(BB) Fig.2: Attach decorative groove connector(G) to decorative grooves(D1&D2) and fix them tightly by bolt(AA) and flat washer (BB). Fig.3: Attach Post(A) to decorative grooves(D1&D2) and fix them tightly by bolt(CC) and flat washer(BB),. Fig.4: Attach decorative grooves(D1, D2) to post(A)from the outside and fx them tightly by bolt(AA). Fig.
/ 10 Fig.7: Use bolt(AA)and flat washer(BB) to lock corner support(K) to groove(D1, D2)。 Fig.8: Fig.
/ 10 Fig.9: Use bolt(AA) and washer(BB)to lock beam(E) to roof connector(M) Fig.10: Connect piece(O) on the top of post(A),using bolt(AA)and washer(BB) to lock the bottom of corner beam(E), post(A) and connect piece(O) together. Fig.11: Use bolt(AA) and flat washer(BB) to lock middle beam(F) to roof connector(M). Fig.12:Use bolt(AA) and washer(BB) to lock the middle beam(F) to the decorative groove (D1、D2) Fig.13:Put small roof cover(L) on roo connector (M)，Assemble Hook(N) to the roof connector(M).
/ 10 Fig.14: Insert PC board(R1) into the gazebo top, and then insert slot(H1) and PC board(R2) into the gazebo top. Use the same method to install the PC board(R4) and PC board(R5). Fig.15: Cover the bottom of PC boards with “F” Baffle(I1). Insert “F” Baffle ( I2) in the same way Fig.16: Insert middle plate(Q2) into the bottom of middle beam(F) by bolt(AA) and washer(BB). Fig.17: Insert corner plate(Q1) into the bottom of corner beam(E) by bolt(AA) and washer(BB).
/ 10 Fig.18: Use hook(GG) to attach the netting(S) to the netting tube. Fig.19: Use the velcro strap to connect netting(S) to the post(A). Fig.20: Fix the gazebo on the ground using stake(FF).
/ 10 Care and Maintenance Our steel components for garden accessories and furniture are treated with rust inhibiting paint that protects it from rusting. However, due to the nature of steel, surface oxidation (rusting) will occur once these protective coatings are scratched. This is not a defect and thus not covered by the warranty. To minimize this condition, we recommend care when assembling & handling the product to prevent scratching the paint.
