WMIA-199N Product Specification The QIG for Wireless 11a/b/g/n Mini PCI Module WMIA-199N Product Specification Product Description Draft IEEE 802.11n compliant 2.4GHz & 5GHz WLAN Mini-PCI Module Lead-Free RoHs compliant Host Interface 32-bit miniPCI, Type III A Operating Voltage DC 3.3V ± 5% Chipset Mac/BB AR9160 Process RF Chip AR9106 Power Consumption 11b TX: ≦ 600mA RX: ≦ 600mA 11g/n TX: ≦ 600mA RX: ≦ 600mA 11a/n TX: ≦ 600mA RX: ≦ 600mA Radio Antenna 3 U.
WMIA-199N Product Specification IEEE 802.11n (OFDM/DSSS) φ QAM-64 φ QAM-16 φ QPSK φ BPSK Operating IEEE 802.11a ISM Band Frequency φ USA(FCC): 5.15GHz ~ 5.25 GHz ; 5.725Hz ~ 5.850 GHz; φ Europe(ETSI): 5.15 GHz ~ 5.25 GHz φ Japan(TELEC) : 5.15 GHz ~ 5.35 GHz ; 5.47GHz ~ 5.725GHz IEEE 802.11b/g ISM Band φ USA(FCC): 2.412GHz ~ 2.462 GHz (CH1 ~ CH11) φ Europe(ETSI): 2.412 GHz ~ 2.472 GHz (CH1 ~ CH13) φ Japan(TELEC) : 2.412 GHz ~ 2..472 GHz (CH1 ~ CH13) IEEE 802.11gn 40MHz Band φ USA(FCC): 2.422GHz ~ 2.
WMIA-199N Product Specification Federal Communication Commission and Industry Canada Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC & IC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
WMIA-199N Product Specification IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the FCC / IC authorization is no longer considered valid and the FCC / IC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization.
WMIA-199N Product Specification Europe – EU Declaration of Conformity This device complies with the essential requirements of the R&TTE Directive 1999/5/EC.
WMIA-199N Product Specification Ελληνική [Greek] Français [French] Italiano [Italian] Latviski [Latvian] Lietuvių [Lithuanian] Nederlands [Dutch] Malti [Maltese] Magyar [Hungarian] Polski [Polish] Português [Portuguese] Slovensko [Slovenian] Slovensky [Slovak] Suomi [Finnish] Svenska [Swedish] ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ [name of manufacturer] ΔΗΛΩΝΕΙ ΟΤΙ [type of equipment] ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ.
