Instructions / Assembly

1
09/08/2017
Snuggle Swing
9-36 months / 9-36 mois / 9-36 meses
ENGLISH
OBSERVE THE FOLLOWING STATEMENTS AND WARNINGS TO REDUCE
THE LIKELIHOOD OF SERIOUS OR FATAL INJURY.
THIS PRODUCT IS INTENDED FOR OUTDOOR DOMESTIC FAMILY USE BY
CHILDREN 9 TO 36 MONTHS AND MAXIMUM WEIGHT OF 50 LBS (23 KG).
PLEASE SAVE THIS INSTRUCTION SHEET IN THE EVENT THAT THE
MANUFACTURER HAS TO BE CONTACTED.
TM
21706 (Model Number)
For assistance or replacement parts please contact Simplay3
®
Pour une aide ou un changement de pièces, contactez Simplay3
®
Para obtener ayuda o piezas de repuesto, contacte a Simplay3
®
The Simplay3 Company
9450 Rosemont Drive
Streetsboro, OH 44241
| 1-866-855-0100
| www.simplay3.com
INSTALLATION/ASSEMBLY:
MAINTENANCE INSTRUCTIONS:
OPERATION INSTRUCTIONS:
CAUTION:
Observing the following statements and warnings reduces the likelihood of serious
or fatal injury:
- T o prevent serious injury, children must not use equipment until properly installed.
- Falls onto hard surfaces can result in serious injuries or death. Never install over concrete,
asphalt, packed earth, grass, carpet or other hard surfaces. Carpet over hard oors may
not prevent injury.
- Always use protective surfacing on the ground under and surrounding the playground
equipment according to the enclosed “Consumer Information Sheet for Home
Playground Surfacing Materials.” Maximum fall height protection up to
7 feet (2.1 m) required.
- Place this product on level ground, at least 6 feet (2 m) away from any object. Objects to
be avoided include, but are not limited to, fences, buildings, garages, houses, overhead
branches, laundry lines, or electrical wires.
- Swing seat should be hung no lower than 8” (20 cm) from the ground.
- The seat should be hung at least 15” (38 cm) from the side of the swing set or from
other swings.
- Attachment points should be approximately 18” apart from each other.
- Do not attach this product to other to-fro swinging components such as, but not limited
to, swings, trapeze bars, trapeze rings, gliders or upper body components such as
horizontal ladders.
- The attachment hook should not be hung on a stationary hook (without
a nylon bushing). The metal attachment hook will rub against the metal
stationary hook and result in premature wear. If this hardware is not present
on your set or you are not hanging the swing from a swing set, you must add
hooks with this bushing.
Observing the following statements and warnings reduces the likelihood of serious
or fatal injury:
- Adult supervision required. Do not leave children unattended.
- This product is intended for use by children ages 9 to 36 months. Maximum weight limit
50 lbs (23 kg).
- Only one rider should be allowed on the swing at one time.
- Do not allow children to wear inappropriate items, such as but not limited to, loose
tting clothing, hood and neck drawstrings, scarves, cord-connected items, capes and
ponchos. These items can cause death by strangulation.
- Instruct children on proper swing use for their safety:
Do not swing empty seats.
Do not get o the swing while it is in motion.
Do not walk close to, in front of, behind, or between moving items.
Do not twist chains or ropes or loop them over the top support bar since this may reduce
their strength.
Do not use the equipment in a manner other than intended.
Do not allow children to climb on product when product is wet.
Do not attach items to the product that are not specically designed for use with the
product such as, but not limited to, jump ropes, clotheslines, pet leashes, cables and
chains, as they may cause a strangulation hazard.
Always wear well-tting and full foot enclosing footwear. Inappropriate footwear includes
clogs, ip-ops and sandals.
Always sit with full weight in the center of the seat.
Children should keep hands free of objects, inside of swing, and hold onto the ropes.
Remove bike or other sports helmet before playing on this product.
WARNING: FAILURE TO PERFORM PERIODIC CHECKS COULD CAUSE INJURY.
The following checks should be performed at the beginning of each season and twice
monthly during the usage period except as noted:
- Reinstall any plastic parts, such as swing seats or any other items that were removed for
the cold season.
- Check metal parts for rust. If found, sand and repaint using a nonlead-based paint
meeting the requirements of 16 CFR 1303.
- Check all wood members for deterioration and splinters. Sand splinters and replace
deteriorating wood members.
- Tighten all hardware.
- Check all protective coverings on bolts, pipes, edges, and corners. Replace if they are
loose, cracked, or missing.
- Rake and check depth of loose ll protective surfacing materials to prevent compaction
and to maintain appropriate depth. Replace as necessary.
- Lubricate all metallic moving parts at the beginning and monthly during the play season.
- Check all moving parts at the beginning and monthly during the play season; including
swing seats, ropes, cables, and chains for wear, rust, or other deterioration. Replace if any
of these conditions exist.
- Take this product indoors or do not use when temperatures fall below 32°F/0°C.
WARNING:
WARNING:
WARNING:
- Strangulation hazard
Failure to follow these instructions may create a strangulation hazard.
Do not allow children to wear inappropriate items, such as but not limited to,
loose tting clothing, hood and neck drawstrings, scarves, cord-connected
items, capes and ponchos. These items can cause death by strangulation.
Do not attach items to the product that are not specically designed for use
with the product such as, but not limited to, jump ropes, clotheslines, pet
leashes, cables and chains, as they may cause a strangulation hazard.
Remove bike or other sports helmet before playing on this product.
- Never cross the shoulder straps. Ensure straps are snug and traybar is pulled
close to child.
- Fall hazard
Always use the restraint system; rotate tray up, and latch straps.
Adjust straps to appropriately secure child.
- Falls onto hard surfaces can result in serious injuries or death. Never install
over concrete, asphalt, packed earth, grass, carpet or other hard surfaces.
Carpet over hard oors may not prevent injury.
- Always use protective surfacing on the ground under and surrounding the
playground equipment according to the enclosed “Consumer Information
Sheet for Home Playground Surfacing Materials.” Maximum fall height
protection up to 7 feet (2.1 m) required.
- Adult assembly required
- To prevent serious injury, children must not use equipment until properly installed.
- Adult supervision required. Do not leave child unattended in swing.
- This product is intended for outdoor, domestic family use by children 9 to 36
months and maximum weight of 50 lbs.
- Follow all installation assembly instructions.
- Instruct children on proper swing use and their safety.
- Perform periodic maintenance checks.
DISPOSAL:
- Disassemble and dispose of equipment in such a manner that no hazardous
conditions, such as but not limited to, small parts and sharp edges, exist at the time
equipment is discarded.
- Please recycle when possible. Disposal must be in compliance with all government
regulations.
| 56221706100
